Anlage 9 - Verwendungsbereich
Gutachten 366-0111-14-WIRD
zur Erteilung der ECE (E1) 124R- 000610
ANLAGE: 9.1 Radtyp: 612
Hersteller: Momo S.r.l. Stand: 18.05.2014
__________________________________________________________________________________________________________________
Seite: 1 von 2
Manufacturer : AUDI
Wheel dates:
Wheel size according to standard : 6 1/2 J X 15 H2 Off set(mm) : 34
Hole circle (mm)/number of holes : 100/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering type (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
100534571 100 PCD Without 57,1 470 1855 03/14
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : AUDI
Mounting parts : spherical collar bolt M14x1,25, length of shaft 27 mm, diameter 25,6
mm,
for Type : 8X
Accessories : fasteners series
Mounting parts : spherical collar bolt M14x1,5, length of shaft 27 mm, diameter 25,6
mm, for Type : 8X
Accessories : fasteners series
Tightening torque for fixing parts : 120 Nm
commercial type: AUDI A1
Vehicle type Approval kW Tires Restrictions of tires Restrictions
8X e1*2007/46*0509*.. 90 205/55R15 12K; 51G 10B; 11N; 51A; 713;
721; 725; 73C; 74D;
76V
commercial type: AUDI A1, S1
Vehicle type Approval kW Tires Restrictions of tires Restrictions
8X e1*2007/46*0414*.. 63 - 136 205/55R15 12A; 51G 10B; 11N; 51A; 713;
721; 725; 73C; 74D;
76V
8X e1*2007/46*0414*.. 63 - 136 205/55R15-88V 713; 721; 725; 73C;
74D
Restrictions
10B) Apart from tires with an M + S tread, the required minimum speed ranges for the tires to be used, taking
load indexes into consideration, can be found in the vehicle documentation, unless deviations have been
defined in the scope of application.
11N) The brake and steering systems and the suspension, except for custom suspension springs, must be
standard, unless governed by other requirements. For custom suspension springs, a national type
approval or a component type approval is necessary; there must be no technical objections to the use of
the wheel/tire combination. If the suspension is modified at the time the custom wheels are fitted, this
modification and its effect on the fitting of custom wheels must be separately evaluated.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Gutachten 366-0111-14-WIRD
zur Erteilung der ECE (E1) 124R- 000610
ANLAGE: 9.1 Radtyp: 612
Hersteller: Momo S.r.l. Stand: 18.05.2014
__________________________________________________________________________________________________________________
Seite: 2 von 2
12A) Snow chains cannot be used unless the expert report offers another retrofitting option for the relevant
vehicle type. For this retrofitting with the restriction 'tires with snow chains' in the requirements column,
the requirements and recommendations there listed must be observed.
12K) The use of snow chains is only permitted if the latter have been approved by the vehicle manufacturer for
this wheel/tire combination (cf. operating instructions).
51A) The inflation pressure specified by the vehicle manufacturer (see operating instructions or tire inflation
pressure indicated on the vehicle) or tire manufacturer must be observed. According to the manufacturer,
tires with run-flat properties may only be used in combination with a tire inflation monitoring system.
51G) This wheel/tire combination may only be used if this tire has already been entered as the standard in
vehicle documents or has been approved by the vehicle manufacturer, see excerpts from EC vehicle
approval (EC certificate of compliance). The load index, speed symbol, M+ S identification, the tire makes
entered in the vehicle documentation and the remarks and recommendations of the vehicle manufacturer
must be observed when this tire size is used.
713) For the wheel balancing only adhesive weights may be applied on the outer face of the rim.
721) The only valves permissible are rubber valves or threaded metal valves with union nuts from the outside
which correspond in all critical points to the standards (DIN, E.T.R.T.O or Tire and Rim) and for which a
rated valve-hole diameter of 11.3 mm is suitable. The valve may not project over the rim edge.
725) Only threaded metal valves may be used for vehicles with a type-specific maximum speed of over 210
km/h+B7.
73C) Only tubeless tires may be used.
74D) Only the standard wheel-fastening elements may be used.
76V) The use of this tire size and offset is only permitted if used as standard.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
