Anlage 9 - Verwendungsbereich
Gutachten 366-0166-14-WIRD
zur Erteilung der ECE (E1) 124R- 000622
ANLAGE: 9.4 Radtyp: 639
Hersteller: Momo S.r.l. Stand: 12.05.2014
__________________________________________________________________________________________________________________
Seite: 1 von 2
Manufacturer : AUDI
Wheel dates:
Wheel size according to standard : 7 J X 16 EH2+ Off set(mm) : 48
Hole circle (mm)/number of holes : 112/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering type (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
511248571 PCD 112 Without 57,1 670 1990 04/14
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : AUDI
Mounting parts : spherical collar bolt M14x1,5, length of shaft 28 mm
Accessories : fasteners series
Tightening torque for fixing parts : 120 Nm
commercial type: AUDI A3, S3
Vehicle type Approval kW Tires Restrictions of tires Restrictions
8V e1*2007/46*0607*.. 77 - 132 205/55R16 91W 12K; 51G 11H; 51A; 711; 714;
723; 73C; 74D; 76V
Restrictions
11H) If the standard spare wheel is used, the car should be driven at moderate speed and for no longer than
necessary. The wheel must be fitted with standard fastening elements. When the spare wheel is used on
four-wheel-drive vehicles, care should be taken to use only tires with identically sized rolling
circumference.
12K) The use of snow chains is only permitted if the latter have been approved by the vehicle manufacturer for
this wheel/tire combination (cf. operating instructions).
51A) The inflation pressure specified by the vehicle manufacturer (see operating instructions or tire inflation
pressure indicated on the vehicle) or tire manufacturer must be observed. According to the manufacturer,
tires with run-flat properties may only be used in combination with a tire inflation monitoring system.
51G) This wheel/tire combination may only be used if this tire has already been entered as the standard in
vehicle documents or has been approved by the vehicle manufacturer, see excerpts from EC vehicle
approval (EC certificate of compliance). The load index, speed symbol, M+ S identification, the tire makes
entered in the vehicle documentation and the remarks and recommendations of the vehicle manufacturer
must be observed when this tire size is used.
711) The wheels may be balanced on the inner side of the rim only with adhesive weights.
714) The wheels may only be balanced on the outer side of the rim by positioning adhesive weights below the
drop center.
723) Only threaded metal valves with union nuts from the outside which correspond in all critical points to the
standards (DIN, E.T.R.T.O or Tire and Rim) and for which a rated valve-hole diameter of 11.3 mm is
suitable are permissible. The valve may not project over the rim edge.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Gutachten 366-0166-14-WIRD
zur Erteilung der ECE (E1) 124R- 000622
ANLAGE: 9.4 Radtyp: 639
Hersteller: Momo S.r.l. Stand: 12.05.2014
__________________________________________________________________________________________________________________
Seite: 2 von 2
73C) Only tubeless tires may be used.
74D) Only the standard wheel-fastening elements may be used.
76V) The use of this tire size and offset is only permitted if used as standard.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
