Ministero delle Infrastrutture e dei Trasporti
Dipartimento per i trasporti e la navigazione
Direzione Generale Territoriale del Nord-Ovest
Centro Prova Autoveicoli di Milano - Sezione di Brescia
Comunicazione riguardante / Communication concerning
E3
- concessione di omologazione / approval granted
- l’estensione dell’omologazione / approval extended
- il rifiuto dell’omologazione / approval refused
- la revoca dell’omologazione / approval withdrawn
- cessazione definitiva della produzione / production definitely
Di un tipo di ruota di sostituzione o dei componenti di questo sistema conforme al Regolamento N°124 Emendamento No 04 alla serie 00. Supplemento 04.
Of a type of Wheel or components of the said system pursuant to Regulation N°124 Emendment No 04 series 00. Supplement 04
Estensione N°:
Omologazione N° / Approval N°: 124R00/04*3135 Extension N°: 10
Marcatura ruota / Wheel marking : E3 124R-013135
Fabbricante della ruota:
1
(Wheel Manufacturer)
Fondmetal S.p.A.
Designazione del tipo di ruota:
2
(Wheel type designation)
WI23-7017
Categoria delle ruote sostitutive: Ruote sostitutive replica parziale (def. 2.4.4)
2.1
(Category of replacement wheels) Pattern part replacement wheels (def. 2.4.4)
Materiali impiegati:
2.2 AlSi 10 Cu
(Construction material)
Metodo di Produzione: Fusione in gravità
2.3
(Method of production) Gravity Casting
Designazione del profili del cerchio:
2.4 7.0 J x 17" H2
(Rim contour designation)
Off-set della ruota: Vedere LISTA APPLICAZIONI (Allegato 1)
2.5
(Wheel inset/outset) See FITMENT LIST (Attachment 1)
Fissaggio della ruota: 5 (cinque) fori
2.6
(Wheel attachment) 5 (five) holes
650Kg 2250mm (versions 5x100 ET40 and ET41)
Portata Massima e circonferenza di rotolamento:
750Kg 2250mm (version 5x112/114,3 ET34, 38, 40, 41, 45, 47)
2.7 700Kg 2250mm (versions 5x112 ET51, 5x114,3 ET48 e 52 )
(Maximum wheel load and respective theoretical rolling circumference) 650Kg 2250mm (version 5x112 ET49)
680Kg 2250mm (version 5x114.3 ET55)
Indirizzo del fabbricante:
3 Via Bergamo, 4 - 24050 - Palosco (Italy)
(Manufacturer's address)
Se del caso, nome e indirizzo del rappresentante del fabbricante: -
4
(If applicable, name and address of manufacturer's representative)
-
Data di presentazione della ruota per le prove di omologazione:
5 17/03/2026
(Wheel submission date for approval test)
Imposta di BOLLO assolta in modo virtuale Pag. 1 / 2
124R00/04*3135 Estensione N° / Extension N°: 10
Servizio tecnico incaricato dell'esecuzione delle prove di
omologazione:
6 Centro Prova Autoveicoli di MILANO con sezione di BRESCIA
(Technical Service responsible for carrying out the approval test)
Data del verbale di prova stilato: 19/07/2019 27/11/2019 04/02/2020 14/07/2021 17/11/2021 13/04/2022 15/07/2022
7
(date of test report issued by the Technical Service) 26/03/2024 18/07/2024 05/06/2025 26/03/2026
Numero del Verbale di prova stilato dal servizio tecnico: 43164 V-BS 44210V-BS 44902V-BS 48027V-BS 48791V-BS 50087V-BS 50832V-BS
8
(Number of test report issued by the Technical Service) 55143V-BS 56068/V-BS 58542/V-BS 60626/BS-26
Osservazioni: Per ragioni di opportunità la marcatura non è stata modificata
9
(Remarks) For expediency reasons the marking has not been changed
10
L'omologazione è rilasciata /rifiutata/estesa/revocata: Estesa
(Approval granted / refused/extended/withdrawn) Extended
11 Se del caso, motivi dell'estensione:
Inserita versione 50_5_114 e aggiornamento lista applicazioni
(Reason(s) for the extension (if applicable) ) Added version 50_5_114 and fitment list updating
12 Luogo:
Brescia
(Place)
13 Data:
(Date)
14 Firma/ Nome:
Il Dirigente
(Signature/ Name)
DCA
D E
Allegati: - Scheda informativa
LISTA APPLICAZIONI / FITMENT LIST
Information Document
(ALLEGATO 1) e l'INDICE DEL FASCICOLO - elenco dei
documenti che costituiscono il dossier dell'omologazione e che
- Istruzioni di montaggio
sono depositati presso l'Autorità che ha rilasciato l'omologazione.
Una copia dei documenti può essere ottenuta su richiesta Fitting instructions
15 WI23-7017_rev10
Annexes: - Accessori
LISTA APPLICAZIONI / FITMENT LIST (ALLEGATO 1) and INDICE DEL Acessories
FASCICOLO - List of documents making up the approval file, deposited
with the competent Authority which granted approval, a copy can be - Disegni
obtained on request.
Drawings
Imposta di BOLLO assolta in modo virtuale Pag. 2 / 2
Approval n°: E3 124R-00/04*3135*10
LISTA APPLICAZIONI / FITMENT LIST (ALLEGATO 1)
Wheel marking: E3 124R-013135
Ministero delle Infrastrutture e dei Trasporti Il Dirigente
Dipartimento per i trasporti e la navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di Milano - Sezione di Brescia Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
Audi Q2 2016 GA e1*2007/46*1552*.. WI23-7017 45_5_112M 5x112 57.1 45.00 OE BOLT OE 215/55 R17
40_5_112L 5x112 57.1 40.00 OE BOLT OE 215/65 R17
Audi Q3 (MK2) 2019 2025 F3 e1*2007/46*1900*.. WI23-7017
40_5_112M 5x112 57.1 40.00 0V.V036 OE 215/65 R17
40_5_112L 5x112 57.1 40.00 OE BOLT OE 215/65 R17
Q3 (MK2)
Audi 2019 2025 F3 e1*2007/46*1900*.. WI23-7017
Sportback
40_5_112M 5x112 57.1 40.00 0V.V036 OE 215/65 R17
34_5_112N 5x112 66.5 34.00 0V.V036 OE 235/65 R17 50 TDI quattro excluded
e1*2007/46*1550*..,
Audi Q5 2017 2024 FY WI23-7017 34_5_112P 5x112 66.5 34.00 OE BOLT OE 235/65 R17 50 TDI quattro excluded
e1*2007/46*1685*..
34_5_112P1 5x112 66.5 34.00 OE BOLT OE 235/65 R17 50 TDI quattro included
34_5_112N 5x112 66.5 34.00 0V.V036 OE 235/65 R17 50 TDI quattro excluded
Audi Q5 Sportback 2021 2024 FY e1*2007/46*1550*.. WI23-7017 34_5_112P 5x112 66.5 34.00 OE BOLT OE 235/65 R17 50 TDI quattro excluded
34_5_112P1 5x112 66.5 34.00 OE BOLT OE 235/65 R17 50 TDI quattro included
e1*2001/116*0369*.., TTRS excluded, Only M+S
Audi TT 2006 2014 8J WI23-7017 47_5_112M 5x112 57.1 47.00 OE BOLT OE 225/50 R17
e1*2001/116*0375*.. (Winter)
e1*2001/116*0369*..,
e1*2001/116*0374*..,
TTRS excluded, Only M+S
Audi TT 2015 8J e1*2001/116*0375*.., WI23-7017 47_5_112M 5x112 57.1 47.00 OE BOLT OE 225/50 R17
(Winter)
e1*2007/46*1686*..,
e1*KS07/46*0054*..
BYD Seal 6 2025 HK e4*2018/858*00275*.. WI23-7017 45_5_114 5x114.3 60.1 45.00 OE NUT OE 225/55 R17
42_5_112M 5x112 57.1 42.00 OE BOLT OE 215/55 R17 FM D.64mm CAP seat
CUPRA (Seat) Raval 2026 KS e9*2018/858*11812*.. WI23-7017
OE D.57mm Cupra/Seat
42_5_112M1 5x112 57.1 42.00 OE BOLT OE 215/55 R17
CAP seat
e4*2018/858*00153*..
Hyundai Kona 2023 SX2, SX2E WI23-7017 50_5_114 5x114.3 67.1 50.00 OE NUT OE 215/60 R17
e4*2018/858*00168*..
Pag. 1 di 4
Ministero delle Infrastrutture e dei Trasporti Il Dirigente
Dipartimento per i trasporti e la navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di Milano - Sezione di Brescia Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
Kia EV3 2024 SV1 e6*2018/858*00331*.. WI23-7017 48_5_114 5x114.3 67.1 48.00 OE NUT OE 215/60 R17
Kia Niro 2022 SG2 e9*2018/858*11241*.. WI23-7017 52_5_114 5x114.3 67.1 52.00 OE NUT OE 215/55 R17 only EV
FM D.60mm CAP seat,
51_5_112E 5x112 57.1 51.00 OE BOLT OE 215/50 R17 Luxury included, X-power
excluded
MG 4 2022 SEH3 e4*2018/858*00093*.. WI23-7017
OE D.57mm MG CAP seat,
51_5_112E1 5x112 57.1 51.00 OE BOLT OE 215/50 R17 Luxury included, X-power
excluded
MG 5 2021 EP22-L e4*2018/858*00053*.. WI23-7017 45_5_112 5x112 57.1 45.00 OE BOLT OE 215/50 R17
51_5_112E 5x112 57.1 51.00 OE NUT OE 215/60 R17 FM D.60mm CAP seat
MG S5 2025 ZS3E e4*2018/858*00236*.. WI23-7017
51_5_112E1 5x112 57.1 51.00 OE NUT OE 215/60 R17 OE D.57mm MG CAP seat
e4*2007/46*1417*..,
MG ZS (5x100) 2021 2024 ZS1, SZS1 WI23-7017 41_5_100 5x100 56.1 41.00 OE BOLT OE 215/55 R17
e4*2007/46*1435*..
e4*2007/46*1417*..,
MG ZS (5x112) 2020 2024 ZS1, SZS1 WI23-7017 41_5_112E 5x112 57.1 41.00 OE BOLT OE 215/50 R17
e4*2007/46*1435*..
MG ZS (5x112) 2024 ZS3A e4*2018/858*00220*.. WI23-7017 38_5_112E 5x112 57.1 38.00 OE BOLT OE 215/55 R17
OE 215/55 R17
Cupra, Cupra R, Brembo
Seat Ateca 2016 5FP e9*2007/46*6394*.. WI23-7017 45_5_112M 5x112 57.1 45.00 OE BOLT
Brake excluded
OE 225/55 R17
Cupra, Cupra R e
Seat Leon 2013 2020 5F e9*2007/46*0094*.. WI23-7017 49_5_112M 5x112 57.1 49.00 OE BOLT OE 225/45 R17
Opt.Brembo brake excluded
OE 205/50 R17
Seat Leon X-Perience 2014 2019 5F e9*2007/46*0094*.. WI23-7017 49_5_112M 5x112 57.1 49.00 OE BOLT OE 205/55 R17
OE 225/45 R17
Seat Tarraco 2019 KN e9*2007/46*6666*.. WI23-7017 40_5_112M 5x112 57.1 40.00 OE BOLT OE 215/65 R17
OE 215/55 R17
215/55 Only for M+S
Skoda Karoq 2017 NU e8*2007/46*0272*.. WI23-7017 45_5_112M 5x112 57.1 45.00 OE BOLT
(Winter)
OE 225/55 R17
Pag. 2 di 4
Ministero delle Infrastrutture e dei Trasporti Il Dirigente
Dipartimento per i trasporti e la navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di Milano - Sezione di Brescia Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
Kodiaq Scout included,
Skoda Kodiaq 2017 2023 NS e8*2007/46*0249*.. WI23-7017 40_5_112M 5x112 57.1 40.00 OE BOLT OE 215/65 R17
Kodiaq RS Included
Skoda Kodiaq (MK2) 2024 PS e8*2018/858*00107*.. WI23-7017 40_5_112M 5x112 57.1 40.00 OE BOLT OE 215/65 R17
e11*2007/46*0243*..,
Skoda Octavia Scout 2012 2020 5E WI23-7017 45_5_112M 5x112 57.1 45.00 OE BOLT OE 225/50 R17
e11*2007/46*0244*..
e11*2001/116*0326*32..,
Skoda Superb 2015 2023 3T e11*2007/46*0014*22.., WI23-7017 40_5_112M 5x112 57.1 40.00 OE BOLT OE 215/55 R17
e8*2007/46*0317*..
Skoda Superb 2024 NZ e8*2018/858*00106*.. WI23-7017 40_5_112M 5x112 57.1 40.00 OE BOLT OE 215/55 R17
e11*2007/46*0010*..,
Skoda Yeti 2009 2017 5L WI23-7017 45_5_112M 5x112 57.1 45.00 OE BOLT OE 225/50 R17
e11*2007/46*0034*..
55_5_114 5x114.3 56.1 55.00 OE NUT OE 225/60 R17 FM D.60mm CAP seat
e13*KS18/858*00022*..
Subaru Crosstrek 2023 G6-SS, G6 WI23-7017
e13*2028/858*00666*..
55_5_1141 5x114.3 56.1 55.00 OE NUT OE 225/60 R17 FM D.64mm CAP seat
55_5_114 5x114.3 56.1 55.00 OE NUT OE 215/50 R17
e13*KS18/858*00022*..
Subaru Impreza 2023 G6-SS, G6 WI23-7017
e13*2028/858*00666*..
55_5_1141 5x114.3 56.1 55.00 OE NUT OE 215/50 R17
Subaru Levorg (Subaru V) 2015 V1 e1*2007/46*1203*03*.. WI23-7017 55_5_114 5x114.3 56.1 55.00 OE NUT OE 215/50 R17
Subaru OutBack 2015 2020 B6 e1*2007/46*1320*.. WI23-7017 55_5_114 5x114.3 56.1 55.00 OE NUT OE 225/65 R17
Golf 7 Variant &
Volkswagen 2014 2019 AUV e1*2007/46*0627*.. WI23-7017 49_5_112M 5x112 57.1 49.00 OE BOLT OE 225/45 R17
Sportsvan
Volkswagen Passat (MK8) 2014 2023 3C e1*2001/116*0307*.. WI23-7017 40_5_112M 5x112 57.1 40.00 OE BOLT OE 215/55 R17
Volkswagen Tayron 2024 R4 e1*2018/858*00403*.. WI23-7017 40_5_112M 5x112 57.1 40.00 OE BOLT OE 215/65 R17
Volkswagen Tiguan 2 2016 2023 5N e1*2001/116*0450*24.. WI23-7017 40_5_112M 5x112 57.1 40.00 OE BOLT OE 215/65 R17 Tiguan R (320 CV) excluded
Volkswagen Tiguan 3 2024 CT e1*2018/858*00302*.. WI23-7017 40_5_112M 5x112 57.1 40.00 OE BOLT OE 215/65 R17
Volkswagen T-Roc 2018 2025 A1 e13*2007/46*1845*.. WI23-7017 45_5_112M 5x112 57.1 45.00 OE BOLT OE 215/55 R17 T-Roc R included
OE 215/55 R17
Volkswagen T-Roc 2025 A2 e1*2018/858*00595*.. WI23-7017 45_5_112M 5x112 57.1 45.00 OE BOLT
OE 225/55 R17
Pag. 3 di 4
Ministero delle Infrastrutture e dei Trasporti Il Dirigente
Dipartimento per i trasporti e la navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di Milano - Sezione di Brescia Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
CONDIZIONI e NOTE GENERALI / GENERIC CONDITION and NOTE
NOTA PRELIMINARE Solo se indicato come equipaggiamento originale (previsto dal costruttore) sulla carta di circolazione del veicolo.
PRELIMINARY NOTE Only if mentioned as original equipment (allowed by vehicle manufacturer) on the vehicle documents.
CATENABILITA' In merito alla catenabilità delle configurazioni indicate fare riferimento alle prescrizioni del costruttore del veicolo.
CHAINABILITY For the chainability of the listed configurations, please refer to the vehicle manufacturer’s prescriptions.
In caso di bulloneria originale del costruttore del veicolo utilizzare la coppia di serraggio prevista dallo stesso costruttore del veicolo.
BULLONERIA - COPPIA DI SERRAGGIO In caso di bulloneria aftermarket fornita da FONDMETAL S.p.A. fare riferiemnto alla prescrizioni di montaggio indicate nell'apposito opuscolo informativo all'interno della
scatola ruota.
In the case of original bolts/nuts, please follow the vehicle manufacturer’s tightening torque recommendations.
BOLT TIGHTENING TORQUE
In the case of aftermarket bolts/nuts supplied by FONDMETAL S.p.A., please make reference to the prescriptions in the leaflet supplied with the wheel.
Fare riferimento alle prescrizioni del costruttore del veicolo normalmente riportate tramite etichette sulle portiere, o all’interno del tappo della benzina o riportate sul
PRESSIONE PNEUMATICI CONSIGLIATA
manuale uso e istruzioni
Please make reference to the vehicle manufacturer’s recommendations, which are normally specified through labels on the vehicle doors or inside the petrol tank plug, or
RECOMMENDED TYRE PRESSURE
mentioned in the vehicle instructions manual.
COMPATIBILITA' TPMS Fare riferimento alla specifica FONDMETAL - TPMS Compatibility
TPMS COMPATIBILITY Please make reference to the speficic FONDMETAL - TPMS Compatibility
Pag. 4 di 4
