Anlage 9 - Verwendungsbereich
Prüfbericht 366-0333-14-WIRD
zur Erteilung der ECE (E1) 124R- 000771
ANLAGE: 9.9 Radtyp: 608
Hersteller: Momo S.r.l. Stand: 20.01.2015
__________________________________________________________________________________________________________________
Seite: 1 von 4
Manufacturer : AUDI, QUATTRO GmbH, VOLKSWAGEN
Wheel dates:
Wheel size according to standard : 7 J X 17 H2 Off set(mm) : 47
Hole circle (mm)/number of holes : 112/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
511247571 PCD112 Without 57,1 665 2150 11/14
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : AUDI
Mounting parts : spherical collar bolt M14x1,5, length of shaft 27 mm, diameter 25,6
mm,
for Type : 8J
Mounting parts : spherical collar bolt M14x1,5, diameter 25,6 mm, for Type : 8J
Tightening torque for fixing parts : 120 Nm
commercial type: AUDI TT
Vehicle type Approval kW Tires Restrictions of tires Restrictions
8J e1*2001/116*0369*.. 118 - 200 225/50R17 M+S 12K; 51G; 52J ;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V; 76Z
8J e1*2001/116*0374*.. 147 - 184 225/50R17 M+S 12K; 51G; 52J 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
8J e1*2001/116*0375*.. 184 225/50R17 M+S 12K; 51G; 52J 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V; 76Z
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : QUATTRO GmbH
Mounting parts : spherical collar bolt M14x1,5, diameter 25,6 mm
Tightening torque for fixing parts : 120 Nm
commercial type: AUDI TT
Vehicle type Approval kW Tires Restrictions of tires Restrictions
8J e1*2001/116*0369*.. 118 - 200 225/50R17 M+S 12K; 51G; 52J ;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V; 76Z
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0333-14-WIRD
zur Erteilung der ECE (E1) 124R- 000771
ANLAGE: 9.9 Radtyp: 608
Hersteller: Momo S.r.l. Stand: 20.01.2015
__________________________________________________________________________________________________________________
Seite: 2 von 4
commercial type: AUDI TT
Vehicle type Approval kW Tires Restrictions of tires Restrictions
8J e1*2001/116*0374*.. 147 - 184 225/50R17 M+S 12K; 51G; 52J 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
8J e1*2001/116*0375*.. 184 225/50R17 M+S 12K; 51G; 52J 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V; 76Z
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : VOLKSWAGEN
Mounting parts : spherical collar bolt M14x1,5, length of shaft 27 mm, diameter 25,6
mm,
for Type : 1KP; 1K; 1T
Mounting parts : spherical collar bolt M14x1,5, diameter 25,6 mm,
for Type : 1T
Accessories : Original bolts/nuts
Mounting parts : spherical collar bolt M14x1,5, diameter 25,6 mm,
for Type : 1T; 1t
Tightening torque for fixing parts : 120 Nm
commercial type: GOLF
Vehicle type Approval kW Tires Restrictions of tires Restrictions
1K e1*2001/116*0242*.. 188 - 199 205/50R17 12K; 51G Only Golf 6;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: GOLF PLUS
Vehicle type Approval kW Tires Restrictions of tires Restrictions
1KP e1*2001/116*0304*.. 75 - 118 225/45R17 12K; 51G Only CrossGolf;
Only to
e1*2001/116*0304*13;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
1KP e1*2001/116*0304*.. 77 - 118 225/45R17 12K; 51G Only CrossGolf 6;
From
e1*2001/116*0304*21;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: TOURAN
Vehicle type Approval kW Tires Restrictions of tires Restrictions
1t DE*2007/46*0506*.. 66 - 125 225/45R17 12K; 51G Sportfahrwerk;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0333-14-WIRD
zur Erteilung der ECE (E1) 124R- 000771
ANLAGE: 9.9 Radtyp: 608
Hersteller: Momo S.r.l. Stand: 20.01.2015
__________________________________________________________________________________________________________________
Seite: 3 von 4
commercial type: TOURAN
Vehicle type Approval kW Tires Restrictions of tires Restrictions
1t e1*2007/46*0506*.. 66 - 125 225/45R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
1T e1*2001/116*0211*.. 66 - 125 225/45R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
1T e1*2001/116*0211*.. 66 - 125 225/45R17 91 12K; 51G from
e1*2001/116*0211*23;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
1T e1*2007/46*0357*.. 66 - 130 225/45R17 91 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
Restrictions
10B) Apart from tires with an M + S tread, the required minimum speed ranges for the tires to be used, taking
load indexes into consideration, can be found in the vehicle documentation, unless deviations have been
defined in the scope of application.
11H) If the standard spare wheel is used, the car should be driven at moderate speed and for no longer than
necessary. The wheel must be fitted with standard fastening elements. When the spare wheel is used on
four-wheel-drive vehicles, care should be taken to use only tires with identically sized rolling
circumference.
11N) The brake and steering systems and the suspension, except for custom suspension springs, must be
standard, unless governed by other requirements. For custom suspension springs, a national type
approval or a component type approval is necessary; there must be no technical objections to the use of
the wheel/tire combination. If the suspension is modified at the time the custom wheels are fitted, this
modification and its effect on the fitting of custom wheels must be separately evaluated.
12K) The use of snow chains is only permitted if the latter have been approved by the vehicle manufacturer for
this wheel/tire combination (cf. operating instructions).
51A) The inflation pressure specified by the vehicle manufacturer (see operating instructions or tire inflation
pressure indicated on the vehicle) or tire manufacturer must be observed. According to the manufacturer,
tires with run-flat properties may only be used in combination with a tire inflation monitoring system.
51G) This wheel/tire combination may only be used if this tire has already been entered as the standard in
vehicle documents or has been approved by the vehicle manufacturer, see excerpts from EC vehicle
approval (EC certificate of compliance). The load index, speed symbol, M+ S identification, the tire makes
entered in the vehicle documentation and the remarks and recommendations of the vehicle manufacturer
must be observed when this tire size is used.
52J) This tire size is only permitted with M+S tread
711) The wheels may be balanced on the inner side of the rim only with adhesive weights.
714) The wheels may only be balanced on the outer side of the rim by positioning adhesive weights below the
drop center.
721) The only valves permissible are rubber valves or threaded metal valves with union nuts from the outside
which correspond in all critical points to the standards (DIN, E.T.R.T.O or Tire and Rim) and for which a
rated valve-hole diameter of 11.3 mm is suitable. The valve may not project over the rim edge.
73C) Only tubeless tires may be used.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0333-14-WIRD
zur Erteilung der ECE (E1) 124R- 000771
ANLAGE: 9.9 Radtyp: 608
Hersteller: Momo S.r.l. Stand: 20.01.2015
__________________________________________________________________________________________________________________
Seite: 4 von 4
74D) Only the standard wheel-fastening elements may be used.
76V) The use of this tire size and offset is only permitted if used as standard.
76Z) This wheel size may only be used in combination with M+S tires
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
