Anlage 9 - Verwendungsbereich
Prüfbericht 366-0333-14-WIRD
zur Erteilung der ECE (E1) 124R- 000771
ANLAGE: 9.12 Radtyp: 608
Hersteller: Momo S.r.l. Stand: 20.01.2015
__________________________________________________________________________________________________________________
Seite: 1 von 1
Manufacturer : BMW AG
Wheel dates:
Wheel size according to standard : 7 J X 17 H2 Off set(mm) : 54
Hole circle (mm)/number of holes : 112/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
511254666 PCD112 Without 66,6 665 2150 11/14
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : BMW AG
Mounting parts : spherical collar bolt M14x1,25, length of shaft 27 mm, diameter 25,6
mm
Accessories : Original bolts/nuts
Tightening torque for fixing parts : 140 Nm
commercial type: MINI, 2er Reihe
Vehicle type Approval kW Tires Restrictions of tires Restrictions
UKL-L e1*2007/46*0371*.. 55 - 141 205/45R17 12K; 51G ;;
711; 714; 721; 73C;
74D
Restrictions
12K) The use of snow chains is only permitted if the latter have been approved by the vehicle manufacturer for
this wheel/tire combination (cf. operating instructions).
51G) This wheel/tire combination may only be used if this tire has already been entered as the standard in
vehicle documents or has been approved by the vehicle manufacturer, see excerpts from EC vehicle
approval (EC certificate of compliance). The load index, speed symbol, M+ S identification, the tire makes
entered in the vehicle documentation and the remarks and recommendations of the vehicle manufacturer
must be observed when this tire size is used.
711) The wheels may be balanced on the inner side of the rim only with adhesive weights.
714) The wheels may only be balanced on the outer side of the rim by positioning adhesive weights below the
drop center.
721) The only valves permissible are rubber valves or threaded metal valves with union nuts from the outside
which correspond in all critical points to the standards (DIN, E.T.R.T.O or Tire and Rim) and for which a
rated valve-hole diameter of 11.3 mm is suitable. The valve may not project over the rim edge.
73C) Only tubeless tires may be used.
74D) Only the standard wheel-fastening elements may be used.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
