Anlage 9 - Verwendungsbereich
Prüfbericht 366-0138-16-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 001048
ANLAGE: 9.1 Radtyp: 16655115-66
Hersteller: MW Aftermarket Srl Stand: 21.09.2017
__________________________________________________________________________________________________________________
Seite: 1 von 3
Manufacturer : GM DAEWOO (ROK), GM KOREA (ROK), GMC, OPEL, OPEL /
VAUXHALL
Wheel dates:
Wheel size according to standard : 6 1/2 J X 16 H2 Off set(mm) : 41
Hole circle (mm)/number of holes : 115/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1777 R1-1777 Without 70 654 2050 47/14
R1-1777 R1-1777 Without 70 670 2025 47/14
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : GM DAEWOO (ROK), GM KOREA (ROK)
Mounting parts : conical collar nut M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts : 140 Nm
commercial type: CHEVROLET CRUZE
Vehicle type Approval kW Tires Restrictions of tires Restrictions
KL1J e4*2001/116*0140*.. 81 205/60R16 1); 2); 33)
215/60R16
92 - 96 205/60R16
96 215/60R16
110 - 120 205/60R16
120 215/60R16
KL1J e4*2001/116*0140*.. 81 205/60R16 *); Dieselmotor;
215/60R16 1); 2); 33)
KL1J e4*2001/116*0140*.. 92 - 120 205/60R16 1); 2); 33)
96 - 120 215/60R16
commercial type: J309, ORLANDO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
CHIO e50*2007/46*0050*.. 104 215/60R16 95V 1); 2); 33)
KL1Y e4*2007/46*0224*.. 96 - 120 215/60R16 95V 1); 2); 33)
KL1YN e4*2007/46*0295*.. 120 215/60R16 95V 1); 2); 33)
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : GMC
Mounting parts : conical collar nut M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts : 140 Nm
commercial type: Volt
Vehicle type Approval kW Tires Restrictions of tires Restrictions
D1JCI e13*2007/46*1158*.. 111 205/60R16 96 1); 2); 33)
M+S
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0138-16-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 001048
ANLAGE: 9.1 Radtyp: 16655115-66
Hersteller: MW Aftermarket Srl Stand: 21.09.2017
__________________________________________________________________________________________________________________
Seite: 2 von 3
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : OPEL, OPEL / VAUXHALL
Mounting parts : conical collar nut M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts : 125 Nm for Type : P-J; P-J/V; Z-B
140 Nm for Type : D1JOI; P-J/SW; P-J/SW/V
commercial type: AMPERA
Vehicle type Approval kW Tires Restrictions of tires Restrictions
D1JOI e13*2007/46*1159*.. 111 205/60R16 96 1); 2); 33)
M+S
commercial type: AST/GTC, ZAFIRA,CASCADA, ZAFIRA TOURER, ASTRA NOTCHBACK
Vehicle type Approval kW Tires Restrictions of tires Restrictions
P-J/SW e4*2007/46*0204*.. 81 - 110 215/60R16 1); 2); 33)
P-J/SW e4*2007/46*0204*.. 74 - 92 205/55R16 91H *); Only ASTRA
74 - 96 215/60R16 95H SPORTS TOURER;
74 - 132 205/60R16 92 1); 2); 33)
M+S
205/60R16 92V
205/65R16 95V
215/60R16 95V
commercial type: ASTRA, ASTRA NOTCHBACK
Vehicle type Approval kW Tires Restrictions of tires Restrictions
P-J e1*2007/46*0141*.. 81 - 96 215/60R16 95H *); notchback;
81 - 132 205/60R16 92V 1); 2); 33)
205/65R16 95V
125 - 132 215/60R16 95V
P-J e1*2007/46*0141*.. 81 - 96 205/55R16 91H *); Hatchback;
215/60R16 95H 1); 2); 33)
81 - 132 205/60R16 92
M+S
205/60R16 92V
205/65R16 95V
215/60R16 95V
commercial type: ASTRA SPORTS TOURER/ZAFIRA TOURER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
P-J/SW/V e4*2007/46*0308*.. 81 - 96 205/55R16 *); Only ASTRA
205/60R16 SPORTS TOURER;
205/65R16 1); 2); 33)
81 - 100 215/60R16
92 205/60R16 M+S
P-J/SW/V e4*2007/46*0308*.. 81 - 110 215/60R16 *); Only ZAFIRA
TOURER;
1); 2); 33)
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0138-16-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 001048
ANLAGE: 9.1 Radtyp: 16655115-66
Hersteller: MW Aftermarket Srl Stand: 21.09.2017
__________________________________________________________________________________________________________________
Seite: 3 von 3
commercial type: ASTRA VAN
Vehicle type Approval kW Tires Restrictions of tires Restrictions
P-J/V e4*2007/46*0309*.. 81 205/55R16 1); 2); 33)
205/60R16
205/60R16 M+S
205/65R16
215/60R16
92 205/60R16 M+S
92 - 96 205/55R16
205/60R16
205/65R16
92 - 100 215/60R16
commercial type: INSIGNIA GRAND SPORT, INSIGNIA SPORTS TOURER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Z-B e8*2007/46*0264*.. 103 - 121 215/60R16 *); Front wheel
drive;
1); 2); 33)
*) The remarks under the listed restrictions/conditions are to be kept. If additional trademarks or sale- names are
listed, so there are only this vehicles permissible. All other vehicles to this one application are not concerned.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series-wheel
must be used.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
