Ministero delle infrastrutture e dei trasporti
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA
Comunicazione riguardante / Communication concerning
E3
- concessione di omologazione / approval granted
- l’estensione dell’omologazione / approval extended
- il rifiuto dell’omologazione / approval refused
- la revoca dell’omologazione / approval withdrawn
- cessazione definitiva della produzione / production definitely
Di un tipo di ruota di sostituzione o dei componenti di questo sistema conforme al Regolamento N°124 Emendamento No 03 alla serie 00. Supplemento 03.
Of a type of Wheel or components of the said system pursuant to Regulation N°124 Emendment No 03 series 00. Supplement 03
Estensione N°:
Omologazione N° / Approval N°: 124R00/03*3235 Extension N°: 02
Marcatura ruota / Wheel marking : E3 124R013235
Fabbricante della ruota:
1
(Wheel Manufacturer)
Fondmetal S.p.A.
Designazione del tipo di ruota:
2
(Wheel type designation)
WI15_7017
Categoria delle ruote sostitutive: Ruote sostitutive replica parziale (def. 2.4.4)
2.1
(Category of replacement wheels) Pattern part replacement wheels (def. 2.4.4)
Materiali impiegati:
2.2 AlSi 10 Cu
(Construction material)
Metodo di Produzione: Fusione in gravità
2.3
(Method of production) Gravity Casting
Designazione del profili del cerchio:
2.4 7.0 J x 17" H2
(Rim contour designation)
Off-set della ruota: Vedere LISTA APPLICAZIONI (Allegato 1)
2.5
(Wheel inset/outset) See FITMENT LIST (Attachment 1)
Fissaggio della ruota: 5 (Cinque) fori
2.6
(Wheel attachment) 5 (Five) holes
650Kg 2150mm for version 5x100 ET48
Portata Massima e circonferenza di rotolamento: 730kg 2150mm for version 5x108 ET42
2.7 900kg 2091mm for versions 5x108 ET46
(Maximum wheel load and respective theoretical rolling circumference) 730kg 2150mm for versions 5x112
710kg 2150mm for versions 5x114.3
Indirizzo del fabbricante:
3 Via Bergamo, 4 - 24050 - Palosco (Italy)
(Manufacturer's address)
Se del caso, nome e indirizzo del rappresentante del fabbricante: -
4
(If applicable, name and address of manufacturer's representative)
-
Data di presentazione della ruota per le prove di omologazione:
5 23/10/2025
(Wheel submission date for approval test)
Imposta di BOLLO assolta in modo virtuale Pag. 1 / 2
124R00/03*3235 Estensione N° / Extension N°: 02
Servizio tecnico incaricato dell'esecuzione delle prove di
omologazione:
6 Centro Prova Autoveicoli di MILANO con sezione di BRESCIA
(Technical Service responsible for carrying out the approval test)
Data del verbale di prova stilato:
7 08/11/2021 02/11/2022 30/10/2025
(date of test report issued by the Technical Service)
Numero del Verbale di prova stilato dal servizio tecnico:
8 48706/V-BS 51627/V-BS 59484/V-BS
(Number of test report issued by the Technical Service)
Osservazioni: Per ragioni di opportunità la marcatura non è stata modificata
9
(Remarks) For expediency reasons the marking has not been changed
10
L'omologazione è rilasciata /rifiutata/estesa/revocata: Estesa
(Approval granted / refused/extended/withdrawn) Extended
Aggiunte versioni ET46 5x112S e ET47 5x112R e relative
11 Se del caso, motivi dell'estensione:
applicazioni
ET46 5x112S and ET47 5x112R versions added with related
(Reason(s) for the extension (if applicable) )
applications
12 Luogo:
Brescia
(Place)
13 Data:
(Date)
C
C
14 Firma/ Nome: GG
(Signature/ Name)
Il Dirigente
G
Allegati: - Scheda informativa
LISTA APPLICAZIONI / FITMENT LIST
Information Document
(ALLEGATO 1) e l'INDICE DEL FASCICOLO - elenco dei
documenti che costituiscono il dossier dell'omologazione e che
- Istruzioni di montaggio
sono depositati presso l'Autorità che ha rilasciato l'omologazione.
Una copia dei documenti può essere ottenuta su richiesta Fitting instructions
15 WI15_7017_rev02
Annexes: - Accessori
LISTA APPLICAZIONI / FITMENT LIST (ALLEGATO 1) and INDICE DEL Acessories
FASCICOLO - List of documents making up the approval file, deposited
with the competent Authority which granted approval, a copy can be - Disegni
obtained on request.
Drawings
Imposta di BOLLO assolta in modo virtuale Pag. 2 / 2
Approval n°: E3 124R-00/03*3235*02
LISTA APPLICAZIONI / FITMENT LIST (ALLEGATO 1)
Wheel marking: E3 124R013235
Ministero delle infrastrutture e dei trasporti Il Dirigente
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
SpaceTourer / e2*2007/46*0530*.. OE 215/60 R17 e-Jumpy Included
Citroen / DS 2016 V WI15_7017 46_5_108X 5x108 65.1 46 OE BOLT
Jumpy e2*2007/46*0531*.. OE 225/55 R17 OE CAP Seat Citroen / Peugeot
SpaceTourer / e2*2007/46*0530*.. OE 215/60 R17 e-Jumpy Included
Citroen / DS 2016 V WI15_7017 46_5_108DX 5x108 65.1 46 0V.V017
Jumpy e2*2007/46*0531*.. OE 225/55 R17 OE CAP Seat Citroen / Peugeot
SpaceTourer / e2*2007/46*0530*.. OE 215/60 R17
Citroen / DS 2016 V WI15_7017 46_5_108D1X 5x108 65.1 46 0V.V017 e-Jumpy Included
Jumpy e2*2007/46*0531*.. OE 225/55 R17
e2*2007/46*0532*..
Fiat Scudo 2022 V WI15_7017 46_5_108D1X 5x108 65.1 46 0V.V017 OE 215/60 R17 e-Scudo Included
e2*2007/46*0533*..
e2*2007/46*0532*.. e-Scudo Included
Fiat Scudo 2022 V WI15_7017 46_5_108X 5x108 65.1 46 OE BOLT OE 215/60 R17
e2*2007/46*0533*.. OE CAP Seat Citroen / Peugeot
e2*2007/46*0532*.. e-Scudo Included
Fiat Scudo 2022 V WI15_7017 46_5_108DX 5x108 65.1 46 0V.V017 OE 215/60 R17
e2*2007/46*0533*.. OE CAP Seat Citroen / Peugeot
Ulysse (MK3) e2*2007/46*0532*..
Fiat 2022 V WI15_7017 46_5_108D1X 5x108 65.1 46 0V.V017 OE 225/55 R17 e-Ulysse Included
e-Ulysse e2*2007/46*0533*..
Ulysse (MK3) e2*2007/46*0532*.. e-Ulysse Included
Fiat 2022 V WI15_7017 46_5_108X 5x108 65.1 46 OE BOLT OE 225/55 R17
e-Ulysse e2*2007/46*0533*.. OE CAP Seat Citroen / Peugeot
Ulysse (MK3) e2*2007/46*0532*.. e-Ulysse Included
Fiat 2022 V WI15_7017 46_5_108DX 5x108 65.1 46 0V.V017 OE 225/55 R17
e-Ulysse e2*2007/46*0533*.. OE CAP Seat Citroen / Peugeot
Mercedes-Benz CLA (C174) 2025 MMCLAE e1*2018/858*00500*… WI15_7017 46_5_112S 5x112 66.5 46 OE BOLT OE 205/55 R17 only front
Mini Aceman J05 2024 JM5 e1*2018/858*00382*.. WI15_7017 47_5_112R 5x112 66.5 47 OE BOLT OE 205/55 R17
Mini Mini F66/F65/F67 2024 FM6 e1*2018/858*00373*.. WI15_7017 47_5_112R 5x112 66.5 47 OE BOLT OE 205/45 R17
Mini Mini J01 2023 JM1 e1*2028/858*00347*.. WI15_7017 47_5_112R 5x112 66.5 47 OE BOLT OE 205/50 R17
e2*2007/46*0532*.. OE 215/60 R17 Vivaro-e Included
Opel Vivaro C 2019 V WI15_7017 46_5_108DX 5x108 65.1 46 - 0V.V017
e2*2007/46*0533*.. OE 225/55 R17 OE CAP Seat Citroen / Peugeot
e2*2007/46*0532*.. OE 215/60 R17
Opel Vivaro C 2019 V WI15_7017 46_5_108D1X 5x108 65.1 46 - 0V.V017 Vivaro-e Included
e2*2007/46*0533*.. OE 225/55 R17
e2*2007/46*0532*.. OE 215/60 R17 Zafira-e Life Included
Opel Zafira Life 2019 V WI15_7017 46_5_108DX 5x108 65.1 46 - 0V.V017
e2*2007/46*0533*.. OE 225/55 R17 OE CAP Seat Citroen / Peugeot
Pag. 1 di 2
Ministero delle infrastrutture e dei trasporti Il Dirigente
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
e2*2007/46*0532*.. OE 215/60 R17
Opel Zafira Life 2019 V WI15_7017 46_5_108D1X 5x108 65.1 46 - 0V.V017 Zafira-e Life Included
e2*2007/46*0533*.. OE 225/55 R17
Traveller / e2*2007/46*0532*.. OE 215/60 R17 e-Expert Included
Peugeot 2016 V WI15_7017 46_5_108X 5x108 65.1 46 - OE BOLT
Expert e2*2007/46*0533*.. OE 225/55 R17 OE CAP Seat Citroen / Peugeot
Traveller / e2*2007/46*0532*.. OE 215/60 R17 e-Expert Included
Peugeot 2016 V WI15_7017 46_5_108DX 5x108 65.1 46 - 0V.V017
Expert e2*2007/46*0533*.. OE 225/55 R17 OE CAP Seat Citroen / Peugeot
Traveller / e2*2007/46*0532*.. OE 215/60 R17
Peugeot 2016 V WI15_7017 46_5_108D1X 5x108 65.1 46 - 0V.V017 e-Expert Included
Expert e2*2007/46*0533*.. OE 225/55 R17
OE 215/60 R17 Proace Electric Included
Toyota ProAce 2016 V e2*2007/46*0538*.. WI15_7017 46_5_108DX 5x108 65.1 46 - 0V.V017
OE 225/55 R17 OE CAP Seat Citroen / Peugeot
OE 215/60 R17
Toyota ProAce 2016 V e2*2007/46*0538*.. WI15_7017 46_5_108D1X 5x108 65.1 46 - 0V.V017 Proace Electric Included
OE 225/55 R17
CONDIZIONI e NOTE GENERALI / GENERIC CONDITION and NOTE
NOTA PRELIMINARE Solo se indicato come equipaggiamento originale (previsto dal costruttore) sulla carta di circolazione del veicolo.
PRELIMINARY NOTE Only if mentioned as original equipment (allowed by vehicle manufacturer) on the vehicle documents.
CATENABILITA' In merito alla catenabilità delle configurazioni indicate fare riferimento alle prescrizioni del costruttore del veicolo.
CHAINABILITY For the chainability of the listed configurations, please refer to the vehicle manufacturer’s prescriptions.
In caso di bulloneria originale del costruttore del veicolo utilizzare la coppia di serraggio prevista dallo stesso costruttore del veicolo.
BULLONERIA - COPPIA DI SERRAGGIO In caso di bulloneria aftermarket fornita da FONDMETAL S.p.A. fare riferiemnto alla prescrizioni di montaggio indicate nell'apposito opuscolo informativo all'interno della
scatola ruota.
In the case of original bolts/nuts, please follow the vehicle manufacturer’s tightening torque recommendations.
BOLT TIGHTENING TORQUE
In the case of aftermarket bolts/nuts supplied by FONDMETAL S.p.A., please make reference to the prescriptions in the leaflet supplied with the wheel.
Fare riferimento alle prescrizioni del costruttore del veicolo normalmente riportate tramite etichette sulle portiere, o all’interno del tappo della benzina o riportate sul manuale
PRESSIONE PNEUMATICI CONSIGLIATA
uso e istruzioni
Please make reference to the vehicle manufacturer’s recommendations, which are normally specified through labels on the vehicle doors or inside the petrol tank plug, or
RECOMMENDED TYRE PRESSURE
mentioned in the vehicle instructions manual.
COMPATIBILITA' TPMS Fare riferimento alla specifica FONDMETAL - TPMS Compatibility
TPMS COMPATIBILITY Please make reference to the speficic FONDMETAL - TPMS Compatibility
Pag. 2 di 2
