Anlage 9 - Verwendungsbereich
Prüfbericht 22-00174-CX-GBM-02
zur Erteilung der ECE (E1) 124R- 000832
ANLAGE: 9.3 Radtyp: 16604108-30
Hersteller: MW Aftermarket Srl Stand: 17.05.2022
______________________________________________________________________________________________________________
Seite: 1 von 2
Manufacturer : CITROEN, PEUGEOT
Wheel dates:
Wheel size according to standard : 6 J X 16 H2 Off set(mm) : 23
Hole circle (mm)/number of holes : 108/4 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1781 R1-1781 Without 65 528 1891 11/22
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : CITROEN
Mounting parts : conical collar bolt M12x1,25, tapered thread 0 Grad
Tightening torque for fixing parts : 100 Nm
commercial type: CITROEN C3, DS3
Vehicle type Approval kW Tires Restrictions of tires Restrictions
S***** e2*2007/46*0003*.. 44 - 88 195/55R16 *); 5-door;
77E; 1); 2); 33)
S***** e2*2007/46*0003*.. 44 - 115 195/55R16 *); 3-door; 5-door;
1); 2); 33)
S***** e2*2007/46*0003*.. 50 - 115 195/55R16 *); 3-door;
77E; 1); 2); 33)
commercial type: CITROEN C3, DS3, DS3 CABRIO,
Vehicle type Approval kW Tires Restrictions of tires Restrictions
S e2*2007/46*0003*.. 60 - 115 195/55R16 81 *); Convertible;
77E; 1); 2); 33)
S e2*2007/46*0003*.. 44 - 88 195/55R16 87 744; 77E; 1); 2);
44 - 110 195/55R16 81 33)
50 - 115 195/55R16 82V
S e2*2007/46*0003*.. 50 - 115 195/55R16 *); 3-door;
77E; 1); 2); 33)
S e2*2007/46*0003*.. 44 - 88 195/55R16 *); 5-door;
77E; 1); 2); 33)
commercial type: CITROEN C3 PICASSO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
SH e2*2001/116*0371*.. 66 - 88 195/55R16 91 1); 2); 33)
SH**** e2*2001/116*0371*..
SH e2*2007/46*0110*.. 66 - 88 195/55R16 84 1); 2); 33)
SH8FN e24*2007/46*0029*.. 67 - 70 195/55R16 91 1); 2); 33)
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 22-00174-CX-GBM-02
zur Erteilung der ECE (E1) 124R- 000832
ANLAGE: 9.3 Radtyp: 16604108-30
Hersteller: MW Aftermarket Srl Stand: 17.05.2022
______________________________________________________________________________________________________________
Seite: 2 von 2
commercial type: CITROEN DS3, C3
Vehicle type Approval kW Tires Restrictions of tires Restrictions
S*8FN e24*2007/46*0028*.. 67 - 70 195/55R16 *); DS3;
1); 2); 33)
S*8FN e24*2007/46*0028*.. 70 195/55R16 87T 1); 2); 33)
Manufacturer : CITROEN, PEUGEOT
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : PEUGEOT
Mounting parts : conical collar bolt M12x1,25, tapered thread 0 Grad
Tightening torque for fixing parts : 100 Nm
commercial type: PEUGEOT 208, 2008
Vehicle type Approval kW Tires Restrictions of tires Restrictions
C e2*2007/46*0070*.. 50 - 115 195/55R16 744; 77E; 1); 2);
33)
C e2*2007/46*0070*.. 50 - 88 195/55R16 81 77E; 1); 2); 33)
*) The remarks under the listed restrictions/conditions are to be kept. If additional trademarks or sale- names are
listed, so there are only this vehicles permissible. All other vehicles to this one application are not concerned.
Restrictions
744) The tightening torque of the custom wheels' fastening elements is specified in the vehicle's operating
manual. Should no tightening torque be specified there, the tightening torque quoted in the expert report
shall apply.
77E) The indirect Tire Pressure Monitoring system must be calibrated. The instructions of the manual must be
followed.
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
must be used.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
