Anlage 9 - Verwendungsbereich
Prüfbericht 366-0540-15-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000850
ANLAGE: 9.3 Radtyp: 15605118-67
Hersteller: MW Aftermarket Srl Stand: 08.03.2017
__________________________________________________________________________________________________________________
Seite: 1 von 2
Manufacturer : CITROEN, FIAT, PEUGEOT
Wheel dates:
Wheel size according to standard : 6 J X 15 H2 Off set(mm) : 68
Hole circle (mm)/number of holes : 118/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1941 R1-1941 Without 71 1000 2126 47/14
R1-1941.MWRO R1-1941 Without 71 1000 2126 38/16
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : CITROEN
Mounting parts : conical collar bolt M14x1,5, tapered thread 60 Grad
Tightening torque for fixing parts : 160 Nm
commercial type: CITROEN JUMPER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Y e3*2001/116*0234*.. 81 - 130 215/70R15C *); from
225/70R15C e3*2001/116*0234*12;
1); 2); 33); 6D)
commercial type: JUMPER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
YB e2*2007/46*0252*.. 81 - 110 215/70R15C *); from
225/70R15C e2*2007/46*0252*03;
1); 2); 33)
YC e2*2007/46*0254*.. 81 - 110 215/70R15C *); from
225/70R15C e2*2007/46*0254*04;
1); 2); 33)
commercial type: JUMPER, RELAY
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Y e3*2007/46*0046*.. 81 - 130 215/70R15C *); from
225/70R15C e3*2007/46*0046*10;
1); 2); 33); 6D)
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : FIAT
Mounting parts : conical collar bolt M14x1,5, tapered thread 60 Grad
Tightening torque for fixing parts : 160 Nm
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0540-15-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000850
ANLAGE: 9.3 Radtyp: 15605118-67
Hersteller: MW Aftermarket Srl Stand: 08.03.2017
__________________________________________________________________________________________________________________
Seite: 2 von 2
commercial type: FIAT DUCATO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
250 e3*2001/116*0232*.. 83 - 130 215/70R15C *); from
225/70R15C e3*2001/116*0232*16;
1); 2); 33); 6D)
250 e3*2007/46*0044*.. 83 - 130 215/70R15C *); from
225/70R15C e3*2007/46*0044*13;
85 - 109 205/70R15C 1); 2); 33)
250 e3*2007/46*0049*.. 96 - 100 215/70R15C *); from
225/70R15C e3*2007/46*0049*10;
1); 2); 33)
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : PEUGEOT
Mounting parts : conical collar bolt M14x1,5, tapered thread 60 Grad
Tightening torque for fixing parts : 160 Nm
commercial type: BOXER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Y e3*2007/46*0045*.. 81 - 130 215/70R15C *); from
225/70R15C e3*2007/46*0045*10;
van; Front wheel
drive;
1); 2); 33); 6D)
commercial type: PEUGEOT BOXER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Y e3*2001/116*0233*.. 81 - 130 215/70R15C *); from
225/70R15C e3*2001/116*0233*12;
1); 2); 33); 6D)
*) The remarks under the listed restrictions/conditions are to be kept. Furthermore only the vehicles (trade name
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series-wheel
must be used.
6D) Not for vehicle models which are solely equipped with 15-inch-wheels and which are only permissible for
vehicle models till a permissible axle load of 2000 kg.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
