Anlage 9 - Verwendungsbereich
Prüfbericht 366-0558-15-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000852
ANLAGE: 9.1 Radtyp: 16605130-70
Hersteller: MW Aftermarket Srl Stand: 08.03.2017
_______________________________________________________________________________________________________________
Seite: 1 von 5
Manufacturer : CITROEN, FIAT, PEUGEOT
Wheel dates:
Wheel size according to standard : 6 J X 16 H2 Off set(mm) : 68
Hole circle (mm)/number of holes : 130/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1636 R1-1636 Without 78,1 1200 2255 47/14
R1-1636.MWRO R1-1636 Without 78,1 1200 2255 47/14
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : CITROEN
Mounting parts : conical collar bolt M16x1,5, tapered thread 60 Grad,
for Type : 250; 250D; Y; 250L
Accessories : Serie
Mounting parts : conical collar bolt M16x1,5, tapered thread 60 Grad, for Type : 230;
YD; 230D; 230L; 244; 244 M; 244 B; Y; 244 L; 244 D
Tightening torque for fixing parts : 180 Nm
commercial type: CITROEN JUMPER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Y e3*2001/116*0234*.. 88 - 130 215/75R16C *); to
225/75R16C e3*2001/116*0234*10;
long wheel base;
1); 2); 33)
230 G712 63 - 94 205/75R16 1); 2); 33)
215/75R16
230D G831 63 - 94 205/75R16 *); van; Front
215/75R16 wheel drive;
zul.GesGew. 3500 kg;
1); 2); 33)
230L G713 63 - 94 205/75R16 1); 2); 33)
215/75R16
244 K908 74 - 94 205/75R16 1); 2); 33)
215/75R16
244 B L306 71 - 94 205/75R16C 1); 2); 33)
215/75R16C
244 D K907 74 - 94 205/75R16 1); 2); 33)
215/75R16
244 L K909 74 - 94 205/75R16 1); 2); 33)
215/75R16
244 M L114 71 - 81 205/75R16C 1); 2); 33)
215/75R16C
250 L774 88 - 116 215/75R16-99 1); 2); 33)
225/75R16
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0558-15-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000852
ANLAGE: 9.1 Radtyp: 16605130-70
Hersteller: MW Aftermarket Srl Stand: 08.03.2017
_______________________________________________________________________________________________________________
Seite: 2 von 5
commercial type: CITROEN JUMPER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
250D L939 88 - 116 215/75R16C *); pickup truck
225/75R16C (series);
1); 2); 33)
250L L773 88 - 116 215/75R16C 1); 2); 33)
225/75R16C
commercial type: JUMPER Cabine Approfondie
Vehicle type Approval kW Tires Restrictions of tires Restrictions
YD e2*2007/46*0256*.. 96 - 110 215/75R16C *); to
225/75R16C e2*2007/46*0256*03;
225/75R16C 1); 2); 33)
M+S
commercial type: JUMPER, RELAY
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Y e3*2007/46*0046*.. 81 - 130 215/75R16C *); to
225/75R16C e3*2007/46*0046*06;
225/75R16C Front wheel drive;
M+S
1); 2); 33)
Y e3*2007/46*0051*.. 96 - 130 215/75R16C *); to
225/75R16C e3*2007/46*0051*07;
225/75R16C 1); 2); 33)
M+S
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : FIAT
Mounting parts : conical collar bolt M16x1,5, tapered thread 60 Grad,
for Type : 250D; 250; 250L
Accessories : Serie
Mounting parts : conical collar bolt M16x1,5, tapered thread 60 Grad,
for Type : 244 B; 230L; 244 D; 230; 244; 250 M; 230D; 230 M; 244 M;
244 L; 250
Tightening torque for fixing parts : 180 Nm
commercial type: FIAT DUCATO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
230 G687 62 - 94 205/75R16 *); van; Front
215/75R16 wheel drive;
1); 2); 33)
230 M K861 70 - 80 205/75R16 1); 2); 33)
215/75R16
230D G830 62 - 94 205/75R16 1); 2); 33)
215/75R16
230L G688 62 - 94 205/75R16 *); only for FZ
215/75R16 with ZGG=3500 kg;
1); 2); 33)
244 K916 81 - 94 205/75R16 1); 2); 33)
215/75R16
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0558-15-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000852
ANLAGE: 9.1 Radtyp: 16605130-70
Hersteller: MW Aftermarket Srl Stand: 08.03.2017
_______________________________________________________________________________________________________________
Seite: 3 von 5
commercial type: FIAT DUCATO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
244 B L051 81 - 94 205/75R16C 1); 2); 33)
215/75R16C
244 D K918 81 - 94 205/75R16 1); 2); 33)
215/75R16
244 L K917 81 - 107 205/75R16 1); 2); 33)
215/75R16
244 M L094 71 - 81 205/75R16C 1); 2); 33)
215/75R16C
250 e3*2001/116*0232*.. 88 - 130 215/75R16C *); to
225/75R16C e3*2001/116*0232*14;
1); 2); 33)
250 e3*2007/46*0044*.. 96 - 130 215/75R16C *); to
225/75R16C e3*2007/46*0044*08;
long wheel base;
1); 2); 33)
250 e3*2007/46*0049*.. 96 - 130 215/75R16C *); to
225/75R16C e3*2007/46*0049*07;
long wheel base;
1); 2); 33)
250 L778 88 - 116 225/75R16 1); 2); 33)
250D L968 88 - 116 215/75R16C *); pickup truck
225/75R16C (series);
1); 2); 33)
250L L779 88 - 116 215/75R16C 1); 2); 33)
225/75R16C
commercial type: FIAT Ducato Natural Power
Vehicle type Approval kW Tires Restrictions of tires Restrictions
250 M N413 100 215/75R16C 1); 2); 33)
116/114
225/75R16C
118/116
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : PEUGEOT
Mounting parts : conical collar bolt M16x1,5, tapered thread 60 Grad,
for Type : 250D; 250L; Y; 250
Accessories : Serie
Mounting parts : conical collar bolt M16x1,5, tapered thread 60 Grad,
for Type : 244; 230D; 230L; 230; 244 M; 230P; 244 L; Y; 244 D
Tightening torque for fixing parts : 180 Nm
commercial type: BOXER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Y e3*2007/46*0045*.. 96 - 130 215/75R16C *); to
225/75R16C e3*2007/46*0045*09;
long wheel base;
1); 2); 33)
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0558-15-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000852
ANLAGE: 9.1 Radtyp: 16605130-70
Hersteller: MW Aftermarket Srl Stand: 08.03.2017
_______________________________________________________________________________________________________________
Seite: 4 von 5
commercial type: BOXER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Y e3*2007/46*0050*.. 96 - 130 215/75R16C *); to
225/75R16C e3*2007/46*0050*07;
long wheel base;
1); 2); 33)
250D L936 88 - 116 215/75R16C *); pickup truck
225/75R16C (series);
1); 2); 33)
commercial type: PEUGEOT BOXER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
Y e3*2001/116*0233*.. 88 - 130 215/75R16C *); to
225/75R16C e3*2001/116*0233*10;
225/75R16C Front wheel drive;
M+S
1); 2); 33)
Y e3*2001/116*0233*.. 88 - 130 215/75R16C *); to
225/75R16C e3*2001/116*0233*10;
not short wheel
base;
1); 2); 33)
230 G716 63 - 94 205/75R16 1); 2); 33)
215/75R16
230D G828 63 - 94 205/75R16 1); 2); 33)
215/75R16
230L G717 63 - 94 205/75R16 1); 2); 33)
215/75R16
230P G718 63 - 80 205/75R16 1); 2); 33)
215/75R16
244 K913 74 - 94 205/75R16 1); 2); 33)
215/75R16
244 D K914 74 - 94 205/75R16 1); 2); 33)
215/75R16
244 L K912 74 - 107 205/75R16 1); 2); 33)
215/75R16
244 M L113 71 - 81 205/75R16C 1); 2); 33)
215/75R16C
250 L771 88 - 116 215/75R16 1); 2); 33)
225/75R16
250L L772 88 - 116 215/75R16C 1); 2); 33)
225/75R16C
*) The remarks under the listed restrictions/conditions are to be kept. Furthermore only the vehicles (trade name
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0558-15-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000852
ANLAGE: 9.1 Radtyp: 16605130-70
Hersteller: MW Aftermarket Srl Stand: 08.03.2017
_______________________________________________________________________________________________________________
Seite: 5 von 5
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series-wheel
must be used.
