Anlage 9 - Verwendungsbereich
Prüfbericht 366-0543-15-WIRD
zur Erteilung der ECE (E1) 124R- 000829
ANLAGE: 9.2 Radtyp: 15654108-27
TUV
Hersteller: MW Aftermarket Srl Stand: 07.10.2015 AUSTRIA
Seite: 1 von 2
Manufacturer : CITROEN, PEUGEOT
Wheel dates:
Wheel size according to standard : 6 1/2 J X 15 H2 Off set(mm) :27
Hole circle (mm)/number of holes : 108/4 centering type : centering fixed
Technical dates, short form
version Version name Centering |Centering Permis (Permiss|Valid
hole material sible — е from
wheel |rolling
Wheel identification Centering (mm) Load |Circumf |Produ
identification erence |ction
(kg) (mm) |date
R1-1735 R1-1735 Without 65 650 1998| 47/14
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : CITROEN
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad,
for Туре : 7*****; В9; 7
Accessories : Serie
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad, for Type : 7*****;
7
Tightening torque for fixing parts : 90 Nm
commercial type: BERLINGO
Vehicle type [Approval KW Tires Restrictions of tires Restrictions
B9 N129 55-66 |195/65R15 91 1); 2); 33)
195/70R15C 98
7 1е2*2001/116*0366*.. [55-88 [195/65R15 91 1); 2); 33)
7 1е2*2001/116*0366*.. 195/70R15C 98
205/65R15-94H
7 e2*2007/46*0002*.. |55-88 |195/65R15 91 1); 2); 33)
195/70R15C 98
205/65R15-94H
7 e2*2007/46*0002*.. |35 195/70R15C *); Berlingo
Electrique;
1); 2); 33)
In built-up vehicle safety апа / or environment-related vehicle systems (such аз tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : PEUGEOT
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad,
for Туре : 7; В9; 7*****
Accessories : Serie
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad,
Тюг Туре : 7*****; 7
Tightening torque for fixing parts : 90 Nm
Benannt unter der Registriernummer КВА-Р 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0543-15-WIRD
zur Erteilung der ECE (E1) 124R- 000829
ANLAGE: 9.2 Radtyp: 15654108-27
TUV
AUSTRIA
Hersteller: MW Aftermarket Srl Stand: 07.10.2015
Seite: 2 von 2
commercial type: PARTNER
Vehicle type_|Approval kW Tires Restrictions of tires Restrictions
B9 N128 55-66 |195/65R15 91 1); 2); 33)
195/70R15C 98
commercial type: PARTNER / RANCH
Vehicle type [Approval kW Tires Restrictions of tires Restrictions
7 e2*2001/116*0365*.. |55-80 [195/70R15C 1); 2); 33)
Vsl e2*2001/116*0365*.. |55-88 |195/65R15 91
195/70R15-98
205/65R15-94H
7 e2*2007/46*0001*.. [55-88 [195/65R15 91 1); 2); 33)
195/70R15C 98
205/65R15-94H
66 195/65R15
7 ©2*2007/46*0001*.. 35 195/70R15C 1); 2); 33)
*) The remarks under the listed restrictions/conditions аге to be kept. Furthermore only the vehicles (trade name
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load апа speed index) апа tyre brand commitments
- а$ well а5 limitations — Ю snow tyres (M+S) from the саг documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible а! vehicle models, which are allowed 10 use steel wheels as standard.
33) The standard fixing parts апа accessories of е vehicle manufacturer Юг the corresponding series-wheel
must be used.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
