Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-04
zur Erteilung der ECE (E1) 124R- 000831
ANLAGE: 9.7 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 17.05.2022
______________________________________________________________________________________________________________
Seite: 1 von 3
Manufacturer : CITROEN, PEUGEOT
Wheel dates:
Wheel size according to standard : 6 J X 15 H2 Off set(mm) : 23
Hole circle (mm)/number of holes : 108/4 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1651 R1-1651 Without 65 525 1937 04/22
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : CITROEN
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad,
for Type : SH; S*****; SH****
Accessories : Serie
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad, for Type :
SH****; D; SH8FN; S; S*8FN; SH
Tightening torque for fixing parts : 100 Nm
commercial type: CITROEN C-ELYSEE
Vehicle type Approval kW Tires Restrictions of tires Restrictions
D e2*2007/46*0225*.. 53 - 85 185/65R15 1); 2); 33)
commercial type: CITROEN C3, DS3
Vehicle type Approval kW Tires Restrictions of tires Restrictions
S***** e2*2007/46*0003*.. 44 - 88 185/65R15 88 *); 3-door; 5-door;
1); 2); 33)
commercial type: CITROEN C3, DS3, DS3 CABRIO,
Vehicle type Approval kW Tires Restrictions of tires Restrictions
S e2*2007/46*0003*.. 81 185/65R15 744; 77E; 1); 2);
33)
S e2*2007/46*0003*.. 44 - 88 185/65R15 81 77E; 1); 2); 33)
185/65R15 88
185/65R15-88H
commercial type: CITROEN C3 PICASSO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
SH e2*2001/116*0371*.. 66 - 70 195/60R15 88 1); 2); 33)
SH**** e2*2001/116*0371*..
SH8FN e24*2007/46*0029*.. 67 - 70 195/60R15 88 1); 2); 33)
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-04
zur Erteilung der ECE (E1) 124R- 000831
ANLAGE: 9.7 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 17.05.2022
______________________________________________________________________________________________________________
Seite: 2 von 3
commercial type: CITROEN DS3, C3
Vehicle type Approval kW Tires Restrictions of tires Restrictions
S*8FN e24*2007/46*0028*.. 67 - 70 185/65R15 *); C3;
744; 1); 2); 33)
S*8FN e24*2007/46*0028*.. 44 - 88 185/65HR15 1); 2); 33)
Manufacturer : CITROEN, PEUGEOT
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : PEUGEOT
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad,
for Type : W*****
Accessories : Serie
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad,
for Type : D; C
Tightening torque for fixing parts : 90 Nm for Type : W*****
100 Nm for Type : C; D
commercial type: PEUGEOT 207
Vehicle type Approval kW Tires Restrictions of tires Restrictions
W***** e2*2001/116*0340*.. 50 - 70 185/65R15 88 *); not Escapade
50 - 88 185/65R15-88H (Ausf. WU****);
1); 2); 33)
W***** e2*2001/116*0340*.. 50 - 70 185/65R15 88 *); not Escapade
50 - 88 185/65R15-88H (Ausf. WU****); not
convertible; Front
wheel drive; not
with increased
chassis clearance;
1); 2); 33)
commercial type: PEUGEOT 208, 2008
Vehicle type Approval kW Tires Restrictions of tires Restrictions
C e2*2007/46*0070*.. 50 - 88 185/65R15 77E; 1); 2); 33)
commercial type: PEUGEOT 301
Vehicle type Approval kW Tires Restrictions of tires Restrictions
D e2*2007/46*0224*.. 53 - 85 185/65R15 80 1); 2); 33)
*) The remarks under the listed restrictions/conditions are to be kept. If additional trademarks or sale- names are
listed, so there are only this vehicles permissible. All other vehicles to this one application are not concerned.
Restrictions
744) The tightening torque of the custom wheels' fastening elements is specified in the vehicle's operating
manual. Should no tightening torque be specified there, the tightening torque quoted in the expert report
shall apply.
77E) The indirect Tire Pressure Monitoring system must be calibrated. The instructions of the manual must be
followed.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-04
zur Erteilung der ECE (E1) 124R- 000831
ANLAGE: 9.7 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 17.05.2022
______________________________________________________________________________________________________________
Seite: 3 von 3
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
must be used.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
