Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.3 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 1 von 3
Manufacturer : CITROEN, PEUGEOT
Wheel dates:
Wheel size according to standard : 6 J X 15 H2 Off set(mm) : 27
Hole circle (mm)/number of holes : 108/4 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1372 R1-1372 Without 65 553 1937 47/14
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : CITROEN
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad
Accessories : Serie
Tightening torque for fixing parts : 90 Nm
commercial type: CITROEN C2
Vehicle type Approval kW Tires Restrictions of tires Restrictions
J*KFU* e2*2001/116*0344*.. 65 185/55R15-82H 1); 2); 3)
J*KFV* e2*2001/116*0284*.. 54 185/55R15-82H 1); 2); 3)
J*NFU* e2*2001/116*0285*.. 80 185/55R15-82H 1); 2); 3)
J*8HX* e2*2001/116*0286*.. 50 185/55R15-82H 1); 2); 3)
J*8HZ* e2*2001/116*0316*.. 50 185/55R15-82H 1); 2); 3)
commercial type: CITROEN C3
Vehicle type Approval kW Tires Restrictions of tires Restrictions
F*HFX* e2*98/14*0256*.. 44 185/60R15 84H 1); 2); 3)
F*KFU* e2*2001/116*0289*.. 65 185/60R15 84H 1); 2); 3)
F*KFV* e2*98/14*0257*.. 54 185/60R15 84H 1); 2); 3)
F*NFU* e2*98/14*0258*.. 80 185/60R15 84H 1); 2); 3)
F*8HX* e2*98/14*0259*.. 50 185/60R15 84H 1); 2); 3)
F*8HY* e2*98/14*0261*.. 66 185/60R15 84H 1); 2); 3)
F*8HZ* e2*2001/116*0317*.. 50 185/60R15 84H 1); 2); 3)
F*9HX* e2*2001/116*0318*.. 66 185/60R15 84H 1); 2); 3)
F*9HZ* e2*2001/116*0329*.. 80 185/60R15 84H 1); 2); 3)
commercial type: CITROEN C3 PLURIEL
Vehicle type Approval kW Tires Restrictions of tires Restrictions
H e2*2001/116*0266*.. 50 - 80 185/65R15-88H 1); 2); 3)
commercial type: CITROEN C4
Vehicle type Approval kW Tires Restrictions of tires Restrictions
L e2*2001/116*0302*.. 65 - 103 195/65R15 91H 1); 2); 3)
L***** e2*2001/116*0302*.. 65 - 103 195/65R15 91H 1); 2); 3)
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.3 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 2 von 3
Manufacturer : CITROEN, PEUGEOT
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : PEUGEOT
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad
Accessories : Serie
Tightening torque for fixing parts : 90 Nm
commercial type: PEUGEOT 1007
Vehicle type Approval kW Tires Restrictions of tires Restrictions
K***** e2*2001/116*0300*.. 50 - 80 185/60R15 84H 1); 2); 3)
commercial type: PEUGEOT 206
Vehicle type Approval kW Tires Restrictions of tires Restrictions
2*KFU* e2*2001/116*0291*.. 65 195/55R15 85H 1); 2); 3)
2*NFU* e2*98/14*0238*.. 80 185/55R15-82V 1); 2); 3)
195/55R15 85H
2*RFK* e2*2001/116*0269*.. 130 195/55R15 82V 1); 2); 3)
2*RFN* e2*98/14*0239*.. 100 195/55R15 *); Station wagon;
1); 2); 3)
2*RFN* e2*98/14*0239*.. 100 185/55R15-82V 1); 2); 3)
195/55R15 85H
2*RHY e2*98/14*0174*.. 66 195/55R15 *); Station wagon;
1); 2); 3)
2*RHY e2*98/14*0174*.. 66 185/55R15 *); Limousine;
195/55R15 1); 2); 3)
2*9HY* e2*2001/116*0343*.. 80 195/55R15 85H 1); 2); 3)
2*9HZ* e2*2001/116*0310*.. 80 195/55R15 85H 1); 2); 3)
commercial type: PEUGEOT 206+
Vehicle type Approval kW Tires Restrictions of tires Restrictions
2 e2*2001/116*0374*.. 50 - 55 185/60R15 84H 1); 2); 3)
2***** e2*2001/116*0374*..
commercial type: PEUGEOT 307
Vehicle type Approval kW Tires Restrictions of tires Restrictions
3*KFU* e2*2001/116*0288*.. 65 195/65R15 91 1); 2); 3)
195/65R15 91H
3*KFU* e2*2001/116*0288*.. 65 195/65R15 91 1); 2); 3)
195/65R15 91H
3*KFW* e2*98/14*0242*.. 55 195/65R15 1); 2); 3)
3*NFU* e2*2001/116*0243*.. 80 195/65R15 91 1); 2); 3)
195/65R15 91H
3*NFU* e2*98/14*0243*.. 80 195/65R15 91 1); 2); 3)
3*RHY* e2*98/14*0245*.. 66 195/65R15 1); 2); 3)
3*8HZ* e2*98/14*0251*.. 50 195/65R15 1); 2); 3)
*) The remarks under the listed restrictions/conditions are to be kept. If additional trademarks or sale- names are
listed, so there are only this vehicles permissible. All other vehicles to this one appl ication are not concerned.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.3 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 3 von 3
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
3) Only for vehicles from date of manufacture 04.2000.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
