Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.6 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 1 von 2
Manufacturer : CITROEN, PEUGEOT
Wheel dates:
Wheel size according to standard : 6 J X 15 H2 Off set(mm) : 18
Hole circle (mm)/number of holes : 108/4 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1369 R1-1369 Without 65 500 1895 47/14
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : CITROEN
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad
Accessories : Serie
Tightening torque for fixing parts : 90 Nm
commercial type: CITROEN BERLINGO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
G*NFU* e2*2001/116*0276*.. 80 185/65R15 88 1); 2); 33)
185/65R15-88H
G*RHY* e2*2001/116*0278*.. 66 185/65R15 88 1); 2); 33)
185/65R15-88H
G*9HW* e2*2001/116*0338*.. 55 185/65R15 88 1); 2); 33)
G*9HX* e2*2001/116*0321*.. 66 185/65R15 88 1); 2); 33)
M*NFU* e2*98/14*0226*.. 80 185/65R15 88 1); 2); 33)
185/65R15-88H
M*RHY e2*98/14*0201*.. 66 185/65R15 88 1); 2); 33)
185/65R15-88H
commercial type: CITROEN PICASSO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
C e2*98/14*0153*.. 65 - 85 185/65R15 88 1); 2); 33)
C***** e2*98/14*0153*.. 65 - 100 185/65R15-88H
66 - 80 185/65HR15
M+S
Manufacturer : CITROEN, PEUGEOT
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : PEUGEOT
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad
Accessories : Serie
Tightening torque for fixing parts : 90 Nm
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.6 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 2 von 2
commercial type: PEUGEOT PARTNER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
G*NFU e2*2001/116*0280*.. 80 185/65R15 88 1); 2); 33)
185/65R15-88H
G*RHY e2*2001/116*0282*.. 66 185/65R15 88 1); 2); 33)
185/65R15-88H
G*9HW* e2*2001/116*0337*.. 55 185/65R15 88 1); 2); 33)
185/65R15-88H
G*9HX* e2*2001/116*0322*.. 66 185/65R15 88 1); 2); 33)
185/65R15-88H
5*NFU* e2*98/14*0230*.. 80 185/65R15 88 1); 2); 33)
185/65R15-88H
5*RHY e2*98/14*0202*.. 66 185/65R15 1); 2); 33)
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
must be used.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
