Anlage 9 - Verwendungsbereich
Prüfbericht 366-0448-16-WIRD/N1
zur Erteilung der ECE (E1) 124R- 001227
ANLAGE: 9.1 Radtyp: 16705108-93
Hersteller: MW Aftermarket Srl Stand: 17.05.2017
__________________________________________________________________________________________________________________
Seite: 1 von 2
Manufacturer : CITROEN, PEUGEOT, Toyota Motor Europe NV/SA
Wheel dates:
Wheel size according to standard : 7 J X 16 H2 Off set(mm) : 46
Hole circle (mm)/number of holes : 108/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1980.MWFR R1-1980 Without 65 950 2092 29/16
R1-1980.MWRO R1-1980 Without 65 950 2092 29/16
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : CITROEN
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad
Tightening torque for fixing parts : 100 Nm
commercial type: Jumpy, Dispatch
Vehicle type Approval kW Tires Restrictions of tires Restrictions
V e2*2007/46*0531*.. 70 - 130 215/65R16 1); 2); 33)
commercial type: Jumpy SpaceTourer
Vehicle type Approval kW Tires Restrictions of tires Restrictions
V e2*2007/46*0530*.. 70 - 130 215/65R16 1); 2); 33)
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : PEUGEOT
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad
Tightening torque for fixing parts : 100 Nm
commercial type: Expert, Expert Traveller
Vehicle type Approval kW Tires Restrictions of tires Restrictions
V e2*2007/46*0533*.. 70 - 130 215/65R16 1); 2); 33)
commercial type: Expert Traveller
Vehicle type Approval kW Tires Restrictions of tires Restrictions
V e2*2007/46*0532*.. 70 215/65R16C 1); 2); 33)
215/65R16C
70 - 110 215/65R16
85 215/65R16C
215/65R16C
110 215/65R16C
215/65R16C
130 215/65R16C
215/65R16C
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0448-16-WIRD/N1
zur Erteilung der ECE (E1) 124R- 001227
ANLAGE: 9.1 Radtyp: 16705108-93
Hersteller: MW Aftermarket Srl Stand: 17.05.2017
__________________________________________________________________________________________________________________
Seite: 2 von 2
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : Toyota Motor Europe NV/SA
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad
Tightening torque for fixing parts : 100 Nm
commercial type: PROACE
Vehicle type Approval kW Tires Restrictions of tires Restrictions
V e2*2007/46*0537*.. 70 - 110 215/65R16 1); 2); 33)
70 - 130 215/65R16C
V e2*2007/46*0538*.. 70 - 110 215/65R16 1); 2); 33)
70 - 130 215/65R16C
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series-wheel
must be used.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
