Ministero delle infrastrutture e dei trasporti
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA
Comunicazione riguardante / Communication
E3
- concessione di omologazione / approval granted
- l’estensione dell’omologazione / approval extended
- il rifiuto dell’omologazione / approval refused
- la revoca dell’omologazione / approval withdrawn
- cessazione definitiva della produzione / production definitely
Di un tipo di ruota di sostituzione o dei componenti di questo sistema conforme al Regolamento N°124 Emendamento No 04 alla serie 00. Supplemento 04.
Of a type of Wheel or components of the said system pursuant to Regulation N°124 Emendment No 04 series 00. Supplement 04
Estensione N°:
Omologazione N° / Approval N°: 124R00/04*3195 Extension N°: 11
Marcatura ruota / Wheel marking : E3 124R-013195
Fabbricante della ruota:
1
(Wheel Manufacturer)
Fondmetal S.p.A.
Designazione del tipo di ruota:
2
(Wheel type designation)
WI238019
Categoria delle ruote sostitutive: Ruote sostitutive replica parziale (def. 2.4.4)
2.1
(Category of replacement wheels) Pattern part replacement wheels (def. 2.4.4)
Materiali impiegati:
2.2 AlSi 10 Cu
(Construction material)
Metodo di Produzione: Fusione in gravità
2.3
(Method of production) Gravity Casting
Designazione del profili del cerchio:
2.4 8.0 J x 19" H2
(Rim contour designation)
Off-set della ruota: Vedere LISTA APPLICAZIONI (Allegato 1)
2.5
(Wheel inset/outset) See FITMENT LIST (Attachment 1)
Fissaggio della ruota: 5 (Cinque) fori
2.6
(Wheel attachment) 5 (Five) holes
Portata Massima e circonferenza di rotolamento: 930Kg 2400mm versions ET53,5 5x114,3
2.7 850Kg 2400mm versions ET50 5x120 e ET58 5x120, ET40 5x112M2
(Maximum wheel load and respective theoretical rolling circumference) 900Kg 2400mm other versions
Indirizzo del fabbricante:
3 Via Bergamo, 4 - 24050 - Palosco (Italy)
(Manufacturer's address)
Se del caso, nome e indirizzo del rappresentante del fabbricante: -
4
(If applicable, name and address of manufacturer's representative)
-
Data di presentazione della ruota per le prove di omologazione:
5 17/11/2025
(Wheel submission date for approval test)
Imposta di BOLLO assolta in modo virtuale Pag. 1 / 2
124R00/04*3195 Estensione N° / Extension N°: 11
Servizio tecnico incaricato dell'esecuzione delle prove di
omologazione:
6 Centro Prova Autoveicoli di MILANO con sezione di BRESCIA
(Technical Service responsible for carrying out the approval test)
Data del verbale di prova stilato: 14/10 17/03 29/04 15/06 02/08/ 22/11 28/09
7
(date of test report issued by the Technical Service) 2020 2021 2021 2021 2021 2021 2022
03/10/2023 13/08/2024 23/10/2024 26/03/2025 26/11/2025
Numero del Verbale di prova stilato dal servizio tecnico: 46234 47162 47463 47774 48179 49163 51242
8
(Number of test report issued by the Technical Service) V-BS V-BS V-BS V-BS V-BS V-BS V-BS
53836/V-BS 56286/V-BS 56750/V-BS 58054/V-BS 59718/V-BS
Osservazioni: Per ragioni di opportunità la marcatura non è stata modificata
9
(Remarks) For expediency reasons the marking has not been changed
10
L'omologazione è rilasciata /rifiutata/estesa/revocata: Estesa
(Approval granted / refused/extended/withdrawn) Extended
inserite versioni ET30 5x112, ET45 5x114.3 ed aggiornamento
11 Se del caso, motivi dell'estensione:
fitment list
added versions ET30 5x112, ET45 5x114.3 and fitment list
(Reason(s) for the extension (if applicable) )
updating
12 Luogo:
Brescia
(Place)
AC D
13 Data:
(Date)
GE
14 Firma/ Nome:
(Signature/ Name)
Il Dirigente I I I
HIIHIL
I HII
Allegati: - Scheda informativa
LISTA APPLICAZIONI / FITMENT LIST
Information Document
(ALLEGATO 1) e l'INDICE DEL FASCICOLO - elenco dei
documenti che costituiscono il dossier dell'omologazione e che
- Istruzioni di montaggio
sono depositati presso l'Autorità che ha rilasciato l'omologazione.
Una copia dei documenti può essere ottenuta su richiesta Fitting instructions
15 WI238019_rev15
Annexes: - Accessori
LISTA APPLICAZIONI / FITMENT LIST (ALLEGATO 1) and INDICE DEL Acessories
FASCICOLO - List of documents making up the approval file, deposited
with the competent Authority which granted approval, a copy can be - Disegni
obtained on request.
Drawings
Imposta di BOLLO assolta in modo virtuale Pag. 2 / 2
Approval n°: E3 124R-00/04*3195*11
LISTA APPLICAZIONI / FITMENT LIST (ALLEGATO 1)
Wheel marking: E3 124R-013195
Ministero delle infrastrutture e dei trasporti Il Dirigente
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
Audi Q2 2016 GA e1*2007/46*1552*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT OE 235/40 R19
Q4 e-tron / Q4 OE 235/55 R19 only front
Audi 2021 FZ e1*2018/858*00006*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT
Sportback OE 255/50 R19 only rear
Audi SQ2 2019 GA e1*2007/46*1552*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT OE 235/40 R19
BYD Han 2022 HC e9*KS18/858*11304*.. WI238019 50_5_120 5x120 64.1 50 OE NUT OE 245/45 R19
e13*KS18/858*00023*..
BYD Seal 2023 EK, EKE WI238019 45_5_120 5x120 64.1 45 OE NUT OE 235/45 R19
e13*2018/858*00639*..
C5 Aircross
Citroen / DS 2025 K e2*2018/858*00064*.. WI238019 43_5_114 5x114,3 65.1 43 OE BOLT OE 235/55 R 19
(BEV-PHEV)
Citroen / DS N°8 2025 K e2*2018/858*00064*.. WI238019 43_5_114 5x114,3 65.1 43 OE BOLT OE 235/55 R 19
OE 225/45 R19
CUPRA (Seat) Ateca 2020 5FP e9*2007/46*6394*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT Only M+S (Winter) Excluded brake system 370mm
(Brembo)
OE 245/40 R19
OE 225/35 R19 only VZ
CUPRA (Seat) Leon 2020 KL e9*2007/46*3167*.. WI238019 43_5_112M2 5x112 57.1 43 OE BOLT
OE 235/35 R19 Akebono brake system included
Included brake system 370mm
40_5_112M 5x112 57.1 40 OE BOLT OE 245/40 R19 (Brembo), no 374mm (Akebono),
VZ5 Excluded
Included brake system 370mm
CUPRA (Seat) Formentor 2021 KM e9*2007/46*4008*.. WI238019 (Brembo), no 374mm (Akebono),
40_5_112M1 5x112 57.1 40 OE BOLT OE 245/40 R19
VZ5 Excluded
OE CAP seat
Included brake system 370mm
40_5_112M2 5x112 57.1 40 OE BOLT OE 245/40 R19
(Brembo), 374mm (Akebono)
OE 235/55 R19 only front
CUPRA (Seat) Tavascan 2024 KR e9*2018/858*11511*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT
OE 255/50 R19 only rear
Pag. 1 di 3
Ministero delle infrastrutture e dei trasporti Il Dirigente
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
DEEPAL
S07 2025 C673 e5*2018/858*00331*.. WI238019 45_5_1141 5x114.3 60.1 45 OE NUT OE 235/55 R 19
(CHANGAN)
Genesis
GV70 2021 JK1 e4*2018/858*00027*.. WI238019 41_5_114 5x114.3 67.1 41 OE BOLT OE 235/55 R19
(Hyundai)
Compass
Jeep (MK4) PHEV / 2025 K e2*2018/858*00064*.. WI238019 43_5_114 5x114,3 65.1 43 OE BOLT OE 235/55 R 19
BEV
Ford Capri 2025 DRP e1*2018/858*00364*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT OE 235/55 R19 only front
Ford Explorer UE 2024 DRP e1*2018/858*00364*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT OE 235/55 R19 only front
Kia EV9 2023 MV1 e4*2018/858*00178*.. WI238019 53_5_114 5x114.3 67.1 53.5 OE NUT OE 255/60 R19
MG Cyberster 2024 EC3A e4*2018/858*00216*.... WI238019 40_5_112E 5x112 57.1 40 OE BOLT OE 245/45 R19 only front
Grandland
Opel (MK2) PHEV / 2024 K e2*2018/858*00064*.. WI238019 43_5_114 5x114.3 65.1 43 OE BOLT OE 235/55 R19
EV
3008 (MK3)
Peugeot 2024 K e2*2018/858*00064*.. WI238019 43_5_114 5x114.3 65.1 43 OE BOLT OE 235/55 R19
PHEV / e-3008
Peugeot 308 (MK2) 2013 2021 L e2*2007/46*0405*.. WI238019 42_5_108W 5x108 65.1 42 0V.V017 OE 235/35 R19 GTi Included
5008 (MK3)
Peugeot 2024 K e2*2018/858*00064*.. WI238019 43_5_114 5x114.3 65.1 43 OE BOLT OE 235/55 R19
PHEV / e-5008
OE 225/45 R19
Seat Ateca 2016 5FP e9*2007/46*6394*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT no CUPRA R (Brembo brake)
OE 245/40 R19
OE 235/55 R19
Skoda Elroq 2024 NY e8*2007/46*0416*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT
OE 255/50 R19 only rear
OE 235/55 R19
Skoda Enyaq iV 2021 NY e8*2007/46*0416*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT
OE 255/50 R19 only rear
OE 225/45 R19
Skoda Karoq 2017 NU e8*2007/46*0272*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT Karoq Scout Included
OE 245/40 R19
Pag. 2 di 3
Ministero delle infrastrutture e dei trasporti Il Dirigente
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
Volkswagen Arteon 2017 3H e1*2007/46*1725*.. WI238019 40_5_112M 5x112 57.1 40 OE BOLT OE 245/40 R19
only front, no brake system
45_5_112L 5x112 57.1 45 OE BOLT OE 235/55 R19 382mm (only brake system
e1*2018/858*00164*.. 358mm)
Volkswagen ID. BUZZ 2022 EB, EBN WI238019
e1*2018/858*00165*..
only front, included brake system
45_5_112L1 5x112 57.1 45 OE BOLT OE 235/55 R19
382mm
OE 235/55 R19 only front
Volkswagen ID.4 2020 E2 e1*2018*858*00004*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT
OE 255/50 R19 only rear
OE 235/55 R19 only front
Volkswagen ID.5 2021 E2 e1*2018*858*00004*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT
OE 255/50 R19 only rear
Volkswagen ID.7 2023 ED e1*2018/858*00306*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT OE 235/50 R19 only front
Volkswagen T-Roc 2025 A2 e1*2018/858*00595*.. WI238019 45_5_112M 5x112 57.1 45 OE BOLT OE 225/45 R 19
Volkswagen T7 (5 holes) 2022 ST e1*2020/683*00018*.. WI238019 58_5_120P 5x120 65.1 58 OE BOLT OE 245/45 R19
Xpeng / Xmotors G9 2023 2025 G9A e5*2018/858*00201*.. WI238019 30_5_112 5x112 60.1 30 OE NUT OE 255/55 R 19
CONDIZIONI e NOTE GENERALI / GENERIC CONDITION and NOTE
NOTA PRELIMINARE Solo se indicato come equipaggiamento originale (previsto dal costruttore) sulla carta di circolazione del veicolo.
PRELIMINARY NOTE Only if mentioned as original equipment (allowed by vehicle manufacturer) on the vehicle documents.
CATENABILITA' In merito alla catenabilità delle configurazioni indicate fare riferimento alle prescrizioni del costruttore del veicolo.
CHAINABILITY For the chainability of the listed configurations, please refer to the vehicle manufacturer’s prescriptions.
In caso di bulloneria originale del costruttore del veicolo utilizzare la coppia di serraggio prevista dallo stesso costruttore del veicolo.
BULLONERIA - COPPIA DI SERRAGGIO In caso di bulloneria aftermarket fornita da FONDMETAL S.p.A. fare riferiemnto alla prescrizioni di montaggio indicate nell'apposito opuscolo informativo all'interno della
scatola ruota.
In the case of original bolts/nuts, please follow the vehicle manufacturer’s tightening torque recommendations.
BOLT TIGHTENING TORQUE
In the case of aftermarket bolts/nuts supplied by FONDMETAL S.p.A., please make reference to the prescriptions in the leaflet supplied with the wheel.
Fare riferimento alle prescrizioni del costruttore del veicolo normalmente riportate tramite etichette sulle portiere, o all’interno del tappo della benzina o riportate sul
PRESSIONE PNEUMATICI CONSIGLIATA
manuale uso e istruzioni
Please make reference to the vehicle manufacturer’s recommendations, which are normally specified through labels on the vehicle doors or inside the petrol tank plug, or
RECOMMENDED TYRE PRESSURE
mentioned in the vehicle instructions manual.
COMPATIBILITA' TPMS Fare riferimento alla specifica FONDMETAL - TPMS Compatibility
TPMS COMPATIBILITY Please make reference to the speficic FONDMETAL - TPMS Compatibility
Pag. 3 di 3
