Anlage 9 - Verwendungsbereich
Prüfbericht 21-00027-CX-GBM-07
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000827
ANLAGE: 9.9 Radtyp: 15604100-23
Hersteller: MW Aftermarket Srl Stand: 22.05.2023
______________________________________________________________________________________________________________
Seite: 1 von 1
Manufacturer : AUTOMOBILES DACIA S.A.
Wheel dates:
Wheel size according to standard : 6 J X 15 H2 Off set(mm) : 43
Hole circle (mm)/number of holes : 100/4 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1724 R1-1724 Without 60 450 1895 47/14
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : AUTOMOBILES DACIA S.A.
Mounting parts : conical collar bolt M12x1,5, tapered thread 60 Grad,
for Type : SD
Accessories : Serie
Mounting parts : conical collar bolt M12x1,5, tapered thread 60 Grad, for Type : SD
Tightening torque for fixing parts : 105 Nm
commercial type: LOGAN,SANDERO,DUSTER,LODGY, DOKKER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
SD e2*2001/116*0314*.. 50 - 77 185/65R15 88 *); Station wagon;
notchback;
Hatchback;
1); 2); 33)
SD e2*2007/46*0030*.. 50 - 77 185/65R15 88 1); 2); 33)
*) The remarks under the listed restrictions/conditions are to be kept. If additional trademarks or sale- names are
listed, so there are only this vehicles permissible. All other vehicles to this one application are not concerned.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
must be used.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
