Anlage 9 - Verwendungsbereich


                                                                                                                  TUV
Prüfbericht 366-0572- 15-WIRD
zur Erteilung der ECE (E1) 124R- 000819
ANLAGE:        9.1                                                            Radtyp: 16704098-8
Hersteller:    MW Aftermarket Srl                                             Stand: 16.12.2015                       AUSTRIA

                                                                                                                           Seite: 1 von 1
Manufacturer                                     : FIAT
Wheel dates:
Wheel size according to standard           : 7 J X 16 H2               Off set(mm)              : 31
Hole circle (mm)/number of holes           : 98/4                      centering type           : centering fixed
Technical dates, short form
version                 Version name                                         Centering    |Centering     Permis       (Permiss|Valid
                                                                             hole         material       sible —      е         from
                                                                                                         wheel        |rolling
                        Wheel identification          Centering              (mm)                        Load         |Circumf    |Produ
                                                      identification                                                  erence      |ction
                                                                                                         (kg)         (mm)     |date
R1-1677                 R1-1677                       Without                        58                         560      1930| 47/14

In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer                       : FIAT
Mounting parts                                   : conical collar bolt M12x1,25, tapered thread 60 Grad,
                                                   for Type : 198
Accessories                                      : Serie
Mounting parts                                   : conical collar bolt M12x1,25, tapered thread 60 Grad, for Type : 844;
                                                    198
Tightening torque for fixing parts               : 100 Nm
 commercial type:                 FIAT BRAVO
 Vehicle type      [Approval               KW              Tires             Restrictions of tires       Restrictions
 198               e3*2001/116*0248*..     [66-88          [205/55R16 91H                                1); 2); 33)
                                            110-121|205/55R16 91V
 198               1е3*2001/116*0288*..    [66             205/55R16 91                                  1); 2); 33)

 commercial type:                 LANCIA DELTA
 Vehicle type  |Approval                 kW                Tires             Restrictions of tires       Restrictions
 844               e3*2001/116*0279*..     [77-140         [205/55R16 91V                                1); 2); 33)
                                           85-140          [195/55R16 91V
 844               е3*2007/46*0008*..      |88             195/55R16 91V                                 1); 2); 33)
                                                           205/55R16 91V

Restrictions

1)        To be kept:
          - the standard wheel size and offset.
          - tyre size with service description (load and speed index) and tyre brand commitments
          - а$ well а5 limitations — Ю snow tyres (M+S) from the саг documents.
          - requirements and limitations of snow chains from the operating licence and the operation manual.

2)        Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33)       The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series-wheel
          must be used.




                                       Benannt unter der Registriernummer KBA-P 00055-00
                        von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
