Anlage 9 - Verwendungsbereich
Prüfbericht 366-0344-15-WIRD
zur Erteilung der ECE (E1) 124R- 001043                                                                          TUV
ANLAGE:        9.2                                                           Radtyp: 13504098-1
Hersteller:    MW Aftermarket Srl                                            Stand: 06.10.2015                       AUSTRIA

                                                                                                                          Seite: 1 моп 1
Manufacturer                                     : FIAT
Wheel dates:
Wheel size according to standard           : 5.00    BX 13 H          Off set(mm)              :35
Hole circle (mm)/number of holes           : 98/4                     centering type           : centering fixed
Technical dates, short form
version                 Version name                                        Centering    |Centering     Permis       (Permiss|Valid
                                                                            hole         material       sible —      е         from
                                                                                                        wheel        |rolling
                        Wheel identification        Centering               (mm)                        Load         |Circumf    |Produ
                                                     identification                                                  erence      |ction
                                                                                                        (kg)         (mm)     |date
R1-1803                 R1-1803                     Without                         58                         375      1765| 47/14

In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer                       : FIAT
Mounting parts                                   : conical collar bolt M12x1,25, tapered thread 60 Grad
Tightening torque for fixing parts               : 100 Nm
 commercial type:                 FIAT PANDA
 Vehicle type_|Approval                  KW               Tires             Restrictions of tires       Restrictions
 169               e3*2001/116*0151*..     [40-55         [155/80R13 79                                 *); Front wheel
                                                                                                        drive;
                                                                                                        1); 2); 33)
 169               е3*2001/116*0287*..     |44            155/80R13 79                                  1); 2); 33)


*) The remarks under the listed restrictions/conditions аге to be kept. Furthermore only the vehicles (trade name
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions

1)        To be kept:
          - the standard wheel size and offset.
          - tyre size with service description (load апа speed index) апа tyre brand commitments
          - а$ well as limitations — Ю snow tyres (M+S) from the саг documents.
          - requirements and limitations of snow chains from the operating licence and the operation manual.
2)        Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33)       The standard fixing parts апа accessories of the vehicle manufacturer for the corresponding series-wheel
          must be used.




                                       Benannt unter der Registriernummer KBA-P 00055-00
                        von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
