Anlage 9 - Verwendungsbereich
Prüfbericht 366-0344-15-WIRD
zur Erteilung der ECE (E1) 124R- 001043
ANLAGE: 9.1                                                                 Radtyp: 13504098-1
                                                                                                                    TUV
                                                                                                                    AUSTRIA
Hersteller: MW Aftermarket Srl                                              Stand: 06.10.2015

                                                                                                                         Seite: 1 von 2
Manufacturer                                    : FIAT
Wheel dates:
Wheel size according to standard           : 5.00 В X 13 H           Off set(mm)              : 33
Hole circle (mm)/number of holes           : 98/4                    centering type           : centering fixed
Technical dates, short form
version                 Version name                                       Centering    |Centering     Permis       (Permiss|Valid
                                                                           hole         material       sible —      е         from
                                                                                                       wheel        |rolling
                        Wheel identification        Centering              (mm)                        Load         |Circumf    |Produ
                                                    identification                                                  erence      |ction
                                                                                                       (kg)         (mm)     |date
R1-1280                 R1-1280                     Without                        58                         315      1672| 47/14
R1-1281                 R1-1281                     Without                        58                         315      1672| 47/14

In built-up vehicle safety апа / or environment-related vehicle systems (such а5 tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle М. anufacturer                    : FIAT
Mounting parts                                  : conical collar bolt M12x1,25, tapered thread 60 Grad
Tightening torque for fixing parts              : 90 Nm
 commercial type:                 FIAT SEICENTO
 Vehicle type_|Approval                    kW            Tires             Restrictions of tires       Restrictions
 187               e3*96/79*0036*..        29-40         145/70R13                                     1); 2); 33)
                                                         155/65R13
 187               e3*98/14*0036*..        29-40         145/70R13   71                                1); 2); 33)
                                                         145/70R13   71
                                                         M+S
                                                         155/65R13   73
                                                         165/55R13   70H
                                           20            155/65R13   73
                                                         M+S
                                                         155/70R13   75
 187               e3*98/14*0036*..        40            145/70R13   71                                1); 2); 33)
                                                         145/70R13 71
                                                         M+S
                                                         155/65R13 73
                                                         155/65R13 73
                                                         M+S
                                                         155/70R13 75

Restrictions

1)        To be kept:
          - the standard wheel size and offset.
          - tyre size with service description (load апа speed index) апа tyre brand commitments
          - аб well а limitations to snow tyres (M+S) from the саг documents.
          - requirements and limitations of snow chains from the operating licence and the operation manual.
2)        Only permissible at vehicle models, which are allowed to use steel wheels as standard.




                                       Benannt unter der Registriernummer KBA-P 00055-00
                        von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
                                                                                Anlage 9 - Verwendungsbereich
Prüfbericht 366-0344-15-WIRD                                                                            —r
zur Erteilung der ECE (E1) 124R- 001043                                                             '   u
ANLAGE:    9.1                                                     Radtyp: 13504098-1
Hersteller: MW Aftermarket Srl                                     Stand:   06.10.2015              В

                                                                                                        Seite: 2 von 2
33)   The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series-wheel
      must be used.




                                 Benannt unter der Registriernummer KBA-P 00055-00
                 von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
