Anlage 9 - Verwendungsbereich
Prüfbericht 366-0553-15-WIRD/N1                                                                                            —r
zur Erteilung eines Nachtrags zur ECE (E1) 124R-                            000835                                 '       u
ANLAGE:       9.3                                                          Radtyp: 16605098-37
Hersteller:   MW Aftermarket Srl                                           Stand: 10.03.2016                       AUSTRIA

                                                                                                                            Seite: 1 моп 1
Manufacturer                                  : FIAT
Wheel dates:
Wheel size according to standard         : 6 J X 16 H2              Off set(mm)              :36,5
Hole circle (mm)/number of holes         : 98/5                     centering type           : centering fixed
Technical dates, short form
version          Version name                                             Centering    |Centering     Permis           (Permiss|Valid
                                                                          hole         material       sible —          е         from
                                                                                                      wheel            |rolling
                     Wheel identification         Centering               (mm)                        Load             |Circumf    |Produ
                                                  identification                                                       erence      |ction
                                                                                                      (kg)             (mm)     |date
R1-1907              R1-1907                      Without                         58                         535          1930| 47/14

In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer                    : FIAT
Mounting parts                                : conical collar bolt M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts            : 110 Nm
 commercial type:              FIAT PUNTO,        PUNTO ABARTH,         FIAT 500L
 Vehicle type_|Approval                KW            Tires                Restrictions of tires       Restrictions
 199             e3*2001/116*0217*..     [62-88        [205/55R16 91H                                 *); Fiat 500L
                                                                                                      Living;
                                                                                                      1); 2); 33)
 199             e3*2001/116*0217*..     [62-88        [205/55R16                                     )
                                                                                                      1); 2); 33)
 199             e3*2001/116*0217*..     |62-88        |205/55R16                                     *); Fiat 500L
                                                                                                      Trekking;
                                                                                                      1); 2); 33)

*) The remarks under the listed restrictions/conditions are to be kept. Furthermore only the vehicles (trade name
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions

1)     To be kept:
       - the standard wheel size апа offset.
       - tyre size with service description (load and speed index) and tyre brand commitments
       - а$ well аз limitations to snow tyres (M+S) from the саг documents.
       - requirements and limitations оё snow chains from the operating licence and the operation manual.
2)     Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33)    The standard fixing parts апа accessories of е           vehicle manufacturer Юг the corresponding series-wheel
       must be used.




                                     Benannt unter der Registriernummer KBA-P 00055-00
                     von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
