Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.11                                                           Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl                                         Stand: 29.09.2022
______________________________________________________________________________________________________________
                                                                                                         Seite: 1 von 1

Manufacturer                             : FORD
Wheel dates:
Wheel size according to standard     : 6 J X 15 H2              Off set(mm)         : 45
Hole circle (mm)/number of holes     : 108/4                    centering type      : centering fixed
 Technical dates, short form
version           Version name                                       Centering Centering     Permis   Permiss     Valid
                                                                     hole      material      sible    ible        from
                                                                                             wheel    rolling
                  Wheel identification         Centering             (mm)                    Load     Circumf     Produ
                                               identification                                         erence      ction
                                                                                             (kg)     (mm)        date
R1-2008           R1-2008                      Without                   63,35                    441      1876     13/18
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer               : FORD
Mounting parts                           : conical collar nut M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts       : 135 Nm
 commercial type:         FIESTA
 Vehicle type Approval           kW       Tires         Restrictions of tires                Restrictions
 JHH          e9*2007/46*3142*.. 52 - 103 195/60R15                                          1); 2); 33)
                                          195/60R15 M+S


Restrictions

1)    To be kept:
      - the standard wheel size and offset.
      - tyre size with service description (load and speed index) and tyre brand commitments
      - as well as limitations to snow tyres (M+S) from the car documents.
      - requirements and limitations of snow chains from the operating licence and the operation manual.
2)    Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33)   The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
      must be used.




                                Benannt unter der Registriernummer KBA-P 00100-10
                  von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
