Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.2 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 1 von 2
Manufacturer : FORD
Wheel dates:
Wheel size according to standard : 6 J X 15 H2 Off set(mm) : 52,5
Hole circle (mm)/number of holes : 108/4 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1338 R1-1338 Without 63,35 505 1876 47/14
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : FORD
Mounting parts : conical collar nut M12x1,5, tapered thread 60 Grad
Accessories : Serie
Tightening torque for fixing parts : 100 Nm
commercial type: FIESTA
Vehicle type Approval kW Tires Restrictions of tires Restrictions
JC3 N070 50 - 74 195/50R15 78 1); 2); 33)
commercial type: FOCUS
Vehicle type Approval kW Tires Restrictions of tires Restrictions
DAW e13*97/27*0037*.. 55 - 85 195/55R15 1); 2); 33)
55 - 96 195/60R15
DAX e13*98/14D0057*.. 86 195/60R15 1); 2); 33)
DAX e13*98/14*0057*.. 83 195/60R15 1); 2); 33)
DBW e13*97/27*0038*.. 55 - 85 195/55R15 1); 2); 33)
66 - 96 195/60R15
DBX e13*98/14D0058*.. 86 195/60R15 1); 2); 33)
DBX e13*98/14*0058*.. 83 195/60R15 1); 2); 33)
DFW e13*97/27*0039*.. 55 - 85 195/55R15 1); 2); 33)
55 - 96 195/60R15
DNW e13*97/27*0040*.. 55 - 85 195/55R15 1); 2); 33)
66 - 96 195/60R15
DNX e13*98/14D0056*.. 86 195/60R15 1); 2); 33)
DNX e13*98/14*0056*.. 83 195/60R15 1); 2); 33)
commercial type: FORD FIESTA
Vehicle type Approval kW Tires Restrictions of tires Restrictions
JD3 e1*2001/116*0210*.. 44 - 74 195/50R15 76 1); 2); 33)
195/50R15 77
50 - 74 195/50R15 78
66 - 110 195/50R15 80
110 185/55R15
185/55R15 M+S
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.2 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 2 von 2
commercial type: FORD FIESTA
Vehicle type Approval kW Tires Restrictions of tires Restrictions
JD3 e1*2001/116*0210*.. 44 - 59 195/50R15 77 1); 2); 33)
50 - 74 195/50R15 78
55 195/50R15 76
66 - 110 185/55R15-80
110 185/55R15 M+S
195/50R15 80
JH1 e1*98/14*0191*.. 44 - 74 195/50R15 77 1); 2); 33)
50 195/50R15 78
51 - 59 195/50R15 76
66 195/50R15 80
JH1 e1*98/14*0191*.. 44 - 74 195/50R15 76 1); 2); 33)
50 195/50R15 78
66 195/50R15 80
74 195/50R15 77
commercial type: FORD FUSION
Vehicle type Approval kW Tires Restrictions of tires Restrictions
JU2 e1*98/14*0194*.. 50 - 74 185/60R15 *); FUSION; up to
195/60R15 e1*98/14*0194*25;
1); 2); 33)
*) The remarks under the listed restrictions/conditions are to be kept. If additional trademarks or sale- names are
listed, so there are only this vehicles permissible. All other vehicles to this one application are not concerned.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
must be used.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
