Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.8 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 1 von 1
Manufacturer : FORD
Wheel dates:
Wheel size according to standard : 6 J X 15 H2 Off set(mm) : 37,5
Hole circle (mm)/number of holes : 108/4 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1923 R1-1923 Without 63,35 495 1937 47/15
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : FORD
Mounting parts : conical collar nut M12x1,5
Tightening torque for fixing parts : 135 Nm
commercial type: B-MAX
Vehicle type Approval kW Tires Restrictions of tires Restrictions
JK8-LPG e13*2007/46*1380*.. 66 185/60R15 1); 2); 33)
185/60R15 M+S
195/60R15
commercial type: B-MAX / EcoSport
Vehicle type Approval kW Tires Restrictions of tires Restrictions
JK8 e9*2007/46*0092*.. 55 - 103 185/60R15 *); Only B-Max;
195/60R15 1); 2); 33)
JK8 e9*2007/46*0092*.. 66 - 103 195/65R15 *); Only ECOSPORT;
Hatchback; Front
wheel drive;
1); 2); 33)
*) The remarks under the listed restrictions/conditions are to be kept. If additional trademarks or sale- names are
listed, so there are only this vehicles permissible. All other vehicles to this one application are not concerned.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
must be used.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
