Anlage 9 - Verwendungsbereich
Prüfbericht 366-0396-14-WIRD
zur Erteilung der ECE (E1) 124R- 000803
ANLAGE: 9.2 Radtyp: 619
Hersteller: Momo S.r.l. Stand: 16.03.2015
__________________________________________________________________________________________________________________
Seite: 1 von 4
Manufacturer : FORD, VOLVO
Wheel dates:
Wheel size according to standard : 8 J X 18 H2 Off set(mm) : 55
Hole circle (mm)/number of holes : 108/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
510855634 PCD 108 Without 63,4 705 2284 03/15
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : FORD
Mounting parts : conical collar nut M12x1,5,
for Type : DXA; BA7
Accessories : OE bolts/nuts
Mounting parts : conical collar nut M14x1,5, for Type : WA6
Accessories : OE bolts/nuts
Tightening torque for fixing parts : 130 Nm for Type : DXA
133 Nm for Type : WA6
140 Nm for Type : BA7
commercial type: FOCUS
Vehicle type Approval kW Tires Restrictions of tires Restrictions
DYB e13*2007/46*1138*.. 63 - 184 235/40R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: FORD MONDEO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
BA7 e13*2001/116*0249*.. 74 - 162 235/40R18 12A; 51G up to
e13*2001/116*0249*25;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: GALAXY, S-MAX
Vehicle type Approval kW Tires Restrictions of tires Restrictions
WA6 e13*2001/116*0185*.. 74 - 176 235/45R18 12A; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0396-14-WIRD
zur Erteilung der ECE (E1) 124R- 000803
ANLAGE: 9.2 Radtyp: 619
Hersteller: Momo S.r.l. Stand: 16.03.2015
__________________________________________________________________________________________________________________
Seite: 2 von 4
commercial type: Grand C-MAX, C-MAX
Vehicle type Approval kW Tires Restrictions of tires Restrictions
DXA e13*2007/46*1103*.. 63 - 134 235/40R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
DXA e13*2007/46*1103*.. 70 - 134 235/40R18 12K; 51G Only C-MAX; MPV;
Front wheel drive;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
DXA e13*2007/46*1103*.. 70 - 134 235/40R18 12K; 51G Only Grand C-MAX;
MPV; Front wheel
drive;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : VOLVO
Mounting parts : conical collar bolt M14x1,5, length of shaft 32 mm,
for Type : G (Kegelbund lose)
Accessories : OE bolts/nuts
Mounting parts : conical collar bolt M14x1,5, length of shaft 32 mm,
for Type : B; F; D; A
Accessories : OE bolts/nuts
Tightening torque for fixing parts : 140 Nm
commercial type: VOLVO S60, V60
Vehicle type Approval kW Tires Restrictions of tires Restrictions
F e9*2007/46*0023*.. 84 - 224 235/40R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: VOLVO S80
Vehicle type Approval kW Tires Restrictions of tires Restrictions
A e9*2001/116*0057*.. 80 - 232 245/40R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
A-2D e1*2001/116*0504*.. 80 - 232 245/40R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: VOLVO V60
Vehicle type Approval kW Tires Restrictions of tires Restrictions
F-N2D e13*2007/46*1157*.. 84 - 224 235/40R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0396-14-WIRD
zur Erteilung der ECE (E1) 124R- 000803
ANLAGE: 9.2 Radtyp: 619
Hersteller: Momo S.r.l. Stand: 16.03.2015
__________________________________________________________________________________________________________________
Seite: 3 von 4
commercial type: V60 HYBRID
Vehicle type Approval kW Tires Restrictions of tires Restrictions
G e9*2007/46*0093*.. 120 - 158 235/45R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: V70, XC70
Vehicle type Approval kW Tires Restrictions of tires Restrictions
B e9*2001/116*0065*.. 80 - 224 245/40R18 12K; 51G VOLVO V70;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
B-N2D e1*2007/46*0495*.. 107 - 224 245/40R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
B-N2E e13*2007/46*1203*.. 84 - 224 245/40R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
B-2D e1*2001/116*0505*.. 100 - 210 245/40R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: XC60
Vehicle type Approval kW Tires Restrictions of tires Restrictions
D e9*2001/116*0068*.. 120 - 224 235/60R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
D-N2D e1*2007/46*0339*.. 120 - 224 235/60R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
D-2D e1*2001/116*0507*.. 120 - 210 235/60R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: XC70
Vehicle type Approval kW Tires Restrictions of tires Restrictions
D-N2E e13*2007/46*1213*.. 120 - 224 235/60R18 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
Restrictions
10B) Apart from tires with an M + S tread, the required minimum speed ranges for the tires to be used, taking
load indexes into consideration, can be found in the vehicle documentation, unless deviations have been
defined in the scope of application.
11H) If the standard spare wheel is used, the car should be driven at moderate speed and for no longer than
necessary. The wheel must be fitted with standard fastening elements. When the spare wheel is used on
four-wheel-drive vehicles, care should be taken to use only tires with identically sized rolling
circumference.
11N) The brake and steering systems and the suspension, except for custom suspension springs, must be
standard, unless governed by other requirements.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0396-14-WIRD
zur Erteilung der ECE (E1) 124R- 000803
ANLAGE: 9.2 Radtyp: 619
Hersteller: Momo S.r.l. Stand: 16.03.2015
__________________________________________________________________________________________________________________
Seite: 4 von 4
12A) Snow chains cannot be used unless the expert report offers another retrofitting option for the relevant
vehicle type. For this retrofitting with the restriction 'tires with snow chains' in the requirements column,
the requirements and recommendations there listed must be observed.
12K) The use of snow chains is only permitted if the latter have been approved by the vehicle manufacturer for
this wheel/tire combination (cf. operating instructions).
51A) The inflation pressure specified by the vehicle manufacturer (see operating instructions or tire inflation
pressure indicated on the vehicle) or tire manufacturer must be observed. According to the manufacturer,
tires with run-flat properties may only be used in combination with a tire inflation monitoring system.
51G) This wheel/tire combination may only be used if this tire has already been entered as the standard in
vehicle documents or has been approved by the vehicle manufacturer, see excerpts from EC vehicle
approval (EC certificate of compliance). The load index, speed symbol, M+ S identification, the tire makes
entered in the vehicle documentation and the remarks and recommendations of the vehicle manufacturer
must be observed when this tire size is used.
711) The wheels may be balanced on the inner side of the rim only with adhesive weights.
714) The wheels may only be balanced on the outer side of the rim by positioning adhesive weights below the
drop center.
721) The only valves permissible are rubber valves or threaded metal valves with union nuts from the outside
which correspond in all critical points to the standards (DIN, E.T.R.T.O or Tire and Rim) and for which a
rated valve-hole diameter of 11.3 mm is suitable. The valve may not project over the rim edge.
73C) Only tubeless tires may be used.
74D) Only the standard wheel-fastening elements may be used.
76V) The use of this tire size and offset is only permitted if used as standard.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
