Anlage 9 - Verwendungsbereich
Prüfbericht 366-0334-14-WIRD
zur Erteilung der ECE (E1) 124R- 000764
ANLAGE: 9.3 Radtyp: 617
Hersteller: Momo S.r.l. Stand: 19.01.2015
__________________________________________________________________________________________________________________
Seite: 1 von 4
Manufacturer : FORD, VOLVO
Wheel dates:
Wheel size according to standard : 7 J X 17 H2 Off set(mm) : 50
Hole circle (mm)/number of holes : 108/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
510850634 PCD108 Without 63,4 680 2255 12/14
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : FORD
Mounting parts : conical collar nut M12x1,5
Tightening torque for fixing parts : 120 Nm for Type : DA3; DA3-RS; DB3; DM2-CNG; DM2-LPG
120 Nm ( Nur C-MAX ) Nm for Type : DM2
130 Nm for Type : DA3-CNG; DA3-LPG; DXA; DXA-LPG; DYB;
DYB-LPG
commercial type: FOCUS
Vehicle type Approval kW Tires Restrictions of tires Restrictions
DA3 e13*2001/116*0144*.. 59 - 107 205/50R17 12K; 51G from
224 205/50R17 Hatchback; 12K; 51G; e13*2001/116*0144*12;
52J 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
215/50R17 91 Hatchback; 12K; 51G;
M+S 52J
DA3-CNG e13*2001/116*1017*.. 91 - 107 205/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
DA3-LPG e13*2001/116*0999*.. 103 - 107 205/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
DA3-RS e13*2001/116*1010*.. 224 205/50R17 M+S 51G; 52J 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V; 76Z
DB3 e13*2001/116*0157*.. 59 - 107 205/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
DYB e13*2007/46*1138*.. 63 - 134 215/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0334-14-WIRD
zur Erteilung der ECE (E1) 124R- 000764
ANLAGE: 9.3 Radtyp: 617
Hersteller: Momo S.r.l. Stand: 19.01.2015
__________________________________________________________________________________________________________________
Seite: 2 von 4
commercial type: FOCUS STH, FOCUS TURNIER
Vehicle type Approval kW Tires Restrictions of tires Restrictions
DYB-LPG e13*2007/46*1289*.. 88 215/50R17 12K; 51G Front wheel drive;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: FORD C-MAX
Vehicle type Approval kW Tires Restrictions of tires Restrictions
DM2-CNG e13*2001/116*1018*.. 91 - 107 205/50R17 87V 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
DM2-LPG e13*2001/116*1000*.. 103 - 107 205/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: FORD C-MAX / KUGA
Vehicle type Approval kW Tires Restrictions of tires Restrictions
DM2 e13*2001/116*0109*.. 66 - 107 205/50R17 12K; 51G Only C-MAX;
711; 714; 721; 73C;
74D
commercial type: Grand C-MAX, C-MAX
Vehicle type Approval kW Tires Restrictions of tires Restrictions
DXA e13*2007/46*1103*.. 70 - 134 215/50R17 12K; 51G Only C-MAX; MPV;
Front wheel drive;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
DXA-LPG e13*2007/46*1288*.. 88 215/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : VOLVO
Mounting parts : conical collar nut M12x1,5,
for Type : M
Mounting parts : conical collar nut M14x1,5,
for Type : A-2D
Mounting parts : conical collar bolt M14x1,5, length of shaft 32 mm,
for Type : B
Mounting parts : conical collar bolt M14x1,5, length of shaft 33 mm,
for Type : F
Mounting parts : conical collar bolt M14x1,5,
for Type : F-N2D; A; B-N2D; B-N2E; B-2D
Tightening torque for fixing parts : 130 Nm ( nur Volvo V40 ) Nm for Type : M
140 Nm for Type : A; A-2D; B; B-N2D; B-N2E; B-2D; F; F-N2D
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0334-14-WIRD
zur Erteilung der ECE (E1) 124R- 000764
ANLAGE: 9.3 Radtyp: 617
Hersteller: Momo S.r.l. Stand: 19.01.2015
__________________________________________________________________________________________________________________
Seite: 3 von 4
commercial type: VOLVO S40, V50, C70, C30,V40
Vehicle type Approval kW Tires Restrictions of tires Restrictions
M e4*2001/116*0076*.. 84 - 187 205/50R17 12K; 51G VOLVO V40;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: VOLVO S60, V60
Vehicle type Approval kW Tires Restrictions of tires Restrictions
F e9*2007/46*0023*.. 84 - 224 215/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: VOLVO S80
Vehicle type Approval kW Tires Restrictions of tires Restrictions
A e9*2001/116*0057*.. 80 - 232 225/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
A-2D e1*2001/116*0504*.. 80 - 232 225/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: VOLVO V60
Vehicle type Approval kW Tires Restrictions of tires Restrictions
F-N2D e13*2007/46*1157*.. 84 - 224 215/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
commercial type: V70, XC70
Vehicle type Approval kW Tires Restrictions of tires Restrictions
B e9*2001/116*0065*.. 80 - 224 225/50R17 12K; 51G VOLVO V70;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
B-N2D e1*2007/46*0495*.. 107 - 224 225/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
B-N2E e13*2007/46*1203*.. 84 - 224 225/50R17 12K; 51G 10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
B-2D e1*2001/116*0505*.. 100 - 210 225/50R17 12K; 51G VOLVO V70;
10B; 11H; 11N; 51A;
711; 714; 721; 73C;
74D; 76V
Restrictions
10B) Apart from tires with an M + S tread, the required minimum speed ranges for the tires to be used, taking
load indexes into consideration, can be found in the vehicle documentation, unless deviations have been
defined in the scope of application.
11H) If the standard spare wheel is used, the car should be driven at moderate speed and for no longer than
necessary. The wheel must be fitted with standard fastening elements. When the spare wheel is used on
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0334-14-WIRD
zur Erteilung der ECE (E1) 124R- 000764
ANLAGE: 9.3 Radtyp: 617
Hersteller: Momo S.r.l. Stand: 19.01.2015
__________________________________________________________________________________________________________________
Seite: 4 von 4
four-wheel-drive vehicles, care should be taken to use only tires with identically sized rolling
circumference.
11N) The brake and steering systems and the suspension, except for custom suspension springs, must be
standard, unless governed by other requirements. For custom suspension springs, a national type
approval or a component type approval is necessary; there must be no technical objections to the use of
the wheel/tire combination. If the suspension is modified at the time the custom wheels are fitted, this
modification and its effect on the fitting of custom wheels must be separately evaluated.
12K) The use of snow chains is only permitted if the latter have been approved by the vehicle manufacturer for
this wheel/tire combination (cf. operating instructions).
51A) The inflation pressure specified by the vehicle manufacturer (see operating instructions or tire inflation
pressure indicated on the vehicle) or tire manufacturer must be observed. According to the manufacturer,
tires with run-flat properties may only be used in combination with a tire inflation monitoring system.
51G) This wheel/tire combination may only be used if this tire has already been entered as the standard in
vehicle documents or has been approved by the vehicle manufacturer, see excerpts from EC vehicle
approval (EC certificate of compliance). The load index, speed symbol, M+ S identification, the tire makes
entered in the vehicle documentation and the remarks and recommendations of the vehicle manufacturer
must be observed when this tire size is used.
52J) This tire size is only permitted with M+S tread
711) The wheels may be balanced on the inner side of the rim only with adhesive weights.
714) The wheels may only be balanced on the outer side of the rim by positioning adhesive weights below the
drop center.
721) The only valves permissible are rubber valves or threaded metal valves with union nuts from the outside
which correspond in all critical points to the standards (DIN, E.T.R.T.O or Tire and Rim) and for which a
rated valve-hole diameter of 11.3 mm is suitable. The valve may not project over the rim edge.
73C) Only tubeless tires may be used.
74D) Only the standard wheel-fastening elements may be used.
76V) The use of this tire size and offset is only permitted if used as standard.
76Z) This wheel size may only be used in combination with M+S tires
