Anlage 9 - Verwendungsbereich
TUV
Prüfbericht 366-0018-16-WIRD
zur Erteilung der ECE (E1) 124R- 001065
ANLAGE: 9.1 Radtyp: 13404100-9 AUSTRIA
Hersteller: MW Aftermarket Srl Stand: 19.01.2016
Seite: 1 von 2
Manufacturer : HYUNDAI MOTOR (IND), KIA
Wheel dates:
Wheel size according 10 standard : 4.00 B X 13 H2 Off set(mm) 146
Hole circle (mm)/number of holes : 100/4 centering type : centering fixed
Technical dates, short form
version Version name Centering | Centering Permis |Permiss Valid
hole material sible |ible from
wheel |rolling
Wheel identification Centering (mm) Load |Circumf [Produ
identification erence |ction
(kg) (тт) |date
R1-1572 R1-1575 Without 54 375 1671] 47/14
In built-up vehicle safety апа / or environment-related vehicle systems (such аб tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : HYUNDAI MOTOR (IND)
Mounting parts : conical collar nut M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts : 100 Nm
commercial type: HYUNDAI 110
Vehicle type_|Approval kW Tires Restrictions of tires Restrictions
PA e4*2001/116*0131*.. |49-63 |155/70R13 75 *); manual gearbox;
not diesel engine;
1); 2); 33)
In built-up vehicle safety апа / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : КА
Mounting parts : conical collar nut M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts : 110 Nm
commercial type: Picanto or Morning
Vehicle type_|Approval kW Tires Restrictions of tires Restrictions
TA е4*2007/46*0256*.. |51-63 |155/70R13 *); ир ю
е4*2007/46*0256*08;
1); 2); 33)
commercial type: PICANTO, SA
Vehicle type_|Approval kW Tires Restrictions of tires Restrictions
BA e4"2001/116*0085*.. |44 -48 |155/70R13 75 1); 2); 33)
*) The remarks under the listed restrictions/conditions аге to be kept. Furthermore only the vehicles (trade пате
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load апа speed index) апа tyre brand commitments
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0018-16-WIRD —
zur Erteilung der ECE (E1) 124R- 001065
' UV
ANLAGE: 9.1 Radtyp: 13404100-9 AUSTRIA
Hersteller: MW Aftermarket Srl Stand: 19.01.2016
Seite: 2 von 2
- а$ well аз limitations to snow tyres (M+S) from е саг documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts апа accessories of the vehicle manufacturer for the corresponding series-wheel
must be used.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
