Anlage 9 - Verwendungsbereich
Prüfbericht 22-00097-CX-GBM-02
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 001058
ANLAGE: 9.3                                                            Radtyp: 14504100-18
Hersteller: MW Aftermarket Srl                                         Stand: 17.07.2023
______________________________________________________________________________________________________________
                                                                                                            Seite: 1 von 1

Manufacturer                             : HYUNDAI MOTOR (IND), KIA
Wheel dates:
Wheel size according to standard     : 5 J X 14 H2              Off set(mm)             : 46
Hole circle (mm)/number of holes     : 100/4                    centering type          : centering fixed
 Technical dates, short form
version           Version name                                       Centering Centering        Permis   Permiss     Valid
                                                                     hole      material         sible    ible        from
                                                                                                wheel    rolling
                  Wheel identification         Centering             (mm)                       Load     Circumf     Produ
                                               identification                                            erence      ction
                                                                                                (kg)     (mm)        date
R1-1571           R1-1571                      Without                        54                     420      1726     47/14
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer               : HYUNDAI MOTOR (IND)
Mounting parts                           : conical collar nut M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts       : 100 Nm
 commercial type:         HYUNDAI I10
 Vehicle type Approval             kW            Tires                Restrictions of tires     Restrictions
 PA           e4*2001/116*0131*.. 49 - 63        175/60R14                                      1); 2); 33)
 PAG          e11*2001/116*0357*.. 47 - 57       165/60R14 75                                   1); 2); 33)


Manufacturer                             : HYUNDAI MOTOR (IND), KIA
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer               : KIA
Mounting parts                           : conical collar nut M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts       : 110 Nm
 commercial type:         PICANTO, SA
 Vehicle type Approval            kW             Tires                Restrictions of tires     Restrictions
 BA           e4*2001/116*0085*.. 44 - 48        165/60R14                                      1); 2); 33)
                                  55             175/60R14


Restrictions

1)    To be kept:
      - the standard wheel size and offset.
      - tyre size with service description (load and speed index) and tyre brand commitments
      - as well as limitations to snow tyres (M+S) from the car documents.
      - requirements and limitations of snow chains from the operating licence and the operation manual.
2)    Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33)   The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
      must be used.




                                Benannt unter der Registriernummer KBA-P 00100-10
                  von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
