Anlage 9 - Verwendungsbereich
Prüfbericht 366-0018-16-WIRD
zur Erteilung der ECE (E1) 124R- 001065                                                                             TUV
ANLAGE: 9.2                                                                 Radtyp: 13404100-9                          AUSTRIA
Hersteller: MW Aftermarket Srl                                              Stand:        19.01.2016

                                                                                                                                 Seite: 1 моп 1
Manufacturer                                  : HYUNDAI      MOTOR      (IND)
Wheel dates:
Wheel size according 10 standard         :4.00 B X 13 H2            Off set(mm)                 146
Hole circle (mm)/number of holes         : 100/4                    centering type              : centering fixed
Technical dates, short form
version          Version name                                             Centering | Centering          Permis         |Permiss Valid
                                                                          hole            material       sible           |ible          from
                                                                                                         wheel          |rolling
                    Wheel identification           Centering              (mm)                           Load           |Circumf        [Produ
                                                   identification                                                       erence          |ction
                                                                                                         (kg)           (тт)            |date
R1-1838             R1-1838                        Without                           54                          375|     _ 1671|        47/14
In built-up vehicle safety апа / ог environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer                    : HYUNDAI      MOTOR      (IND)
Mounting parts                                : conical collar nut M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts            : 100 Nm
 commercial type:             HYUNDAI 110
 Vehicle type_|Approval                  kW          Tires                Restrictions of tires          Restrictions
 PA            e4*2001/116*0131*..       |49-63      |155/70R13 75                                       *); from NT*05;
                                                                                                         manual gearbox; not
                                                                                                         diesel engine;
                                                                                                         1); 2); 33)

*) The remarks under the listed restrictions/conditions are to be kept. Furthermore only the vehicles (trade name
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions

1)    To be kept:
      - the standard wheel size and offset.
      - tyre size with service description (load апа speed index) апа tyre brand commitments
      - а$ well аз limitations to snow tyres (M+S) from е саг documents.
      - requirements and limitations of snow chains from the operating licence and the operation manual.
2)     Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33)   The standard fixing parts апа accessories of the vehicle manufacturer for the corresponding series-wheel
       must be used.




                                     Benannt unter der Registriernummer KBA-P 00055-00
                    von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
