Anlage 9 - Verwendungsbereich
Prüfbericht 366-0550-15-WIRD/N1
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000854
ANLAGE: 9.1                                                            Radtyp: 16506170-80
Hersteller: MW Aftermarket Srl                                         Stand: 02.02.2017
__________________________________________________________________________________________________________________
                                                                                                            Seite: 1 von 1

Manufacturer                             : IVECO
Wheel dates:
Wheel size according to standard : 5 J X 16 H                   Off set(mm)           : 115
Hole circle (mm)/number of holes     : 170/6                    centering type        : centering fixed
Technical dates, short form
version          Version name                                        Centering Centering      Permis  Permiss     Valid
                                                                     hole      material       sible   ible        from
                                                                                              wheel   rolling
                  Wheel identification         Centering             (mm)                     Load    Circumf     Produ
                                               identification                                         erence      ction
                                                                                              (kg)    (mm)        date
R1-1347      R1-1347                           Without                      130                   975      2129    47/14
R1-1347.MWRO R1-1347                           Without                      130                   975      2129    41/16
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer               : IVECO
Mounting parts                           : Flachbundmuttern M20x
Tightening torque for fixing parts       : 500 Nm
 commercial type:            Daily 45C.., 45-..,50C..,50-..
 Vehicle type Approval               kW         Tires                Restrictions of tires    Restrictions
 S3           K687                   63 - 122 195/75R16                                       *); twin tyres;
                                                                                              1); 2); 33)

*) The remarks under the listed restrictions/conditions are to be kept. Furthermore only the vehicles (trade name
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions

1)    To be kept:
      - the standard wheel size and offset.
      - tyre size with service description (load and speed index) and tyre brand commitments
      - as well as limitations to snow tyres (M+S) from the car documents.
      - requirements and limitations of snow chains from the operating licence and the operation manual.
2)    Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33)   The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series-wheel
      must be used.




                                Benannt unter der Registriernummer KBA-P 00055-00
                  von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
