Anlage 9 - Verwendungsbereich
Prüfbericht 366-0378-15-WIRD
zur Erteilung der ECE (E1) 124R- 0001059                                                                       TUV
ANLAGE:       9.1                                                          Radtyp: 15605110-51
Hersteller:   MW Aftermarket Srl                                           Stand: 10.11.2015                       AUSTRIA

                                                                                                                        Seite: 1 моп 1
Manufacturer                                  : OPEL, OPEL / VAUXHALL
Wheel dates:
Wheel size according to standard         : 6 J X 15 H2              Off set(mm)              143
Hole circle (mm)/number of holes         : 110/5                    centering type           : centering fixed
Technical dates, short form
version          Version name                                             Centering    [Centering     Permis       [Permiss|Valid
                                                                          hole         material       sible —      е         from
                                                                                                      wheel        |rolling
                     Wheel identification          Centering              (mm)                        Load         |Circumf    |Produ
                                                   identification                                                  erence      |ction
                                                                                                      (kg)         (mm)     |date
R1-1357              R1-1357                       Without                        65                         615      1937| 47/14

In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer                    : OPEL, OPEL / VAUXHALL
Mounting parts                                : conical collar bolt M12x1,5, tapered thread 60 Grad
Tightening torque for fixing parts            : 110 Nm
 commercial type:              MERIVA-A
 Vehicle type_|Approval               KW             Tires                Restrictions of tires       Restrictions
 X01Monocab      [e1*2001/116*0215*..    [51-92      [185/60R15                                       1); 2); 33)

 commercial type:              OPEL ZAFIRA-A-CNG
 Vehicle type_|Approval               kW     Tires                        Restrictions of tires       Restrictions
 T9BMONOC        |е1*98/14*0200*..       71          195/65R15 91                                     1); 2); 33)
/AB/CNG                                              M+S
                                                     195/65R15 91H

 commercial type:              ZAFIRA-A
 Vehicle type    [Approval               KW          Tires                Restrictions of tires       Restrictions
 T98MONOC        |e1*98/14*0110*..       60-108      |195/65R15                                       *); not OPC;
 AB
                                                                                                      1); 2); 33)

*) The remarks under the listed restrictions/conditions аге to be kept. Furthermore only the vehicles (trade name
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions

1)     To be kept:
       - the standard wheel size and offset.
       - tyre size with service description (load and speed index) and tyre brand commitments
       - as well аз limitations — Ю snow tyres (M+S) from the саг documents.
       - requirements and limitations of snow chains from the operating licence and the operation manual.
2)     Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33)    The standard fixing parts апа accessories of е           vehicle manufacturer Юг the corresponding series-wheel
       must be used.




                                     Benannt unter der Registriernummer KBA-P 00055-00
                     von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
