Anlage 9 - Verwendungsbereich
Prüfbericht 22-00175-CX-GBM-05
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000831
ANLAGE: 9.13 Radtyp: 15604108-29
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 1 von 1
Manufacturer : PSA Automobiles SA
Wheel dates:
Wheel size according to standard : 6 J X 15 H2 Off set(mm) : 32
Hole circle (mm)/number of holes : 108/4 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-2060 R1-2060 Without 65 500 1894 23/22
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : PSA Automobiles SA
Mounting parts : conical collar bolt M12x1,25, tapered thread 60 Grad
commercial type: OPEL CORSA-F ab MJ 2019
Vehicle type Approval kW Tires Restrictions of tires Restrictions
U e2*2007/46*0639*.. 55 185/65R15 744; 77E; 1); 2);
74 - 96 185/65R15 33)
commercial type: PEUGEOT 208, 2008
Vehicle type Approval kW Tires Restrictions of tires Restrictions
U e2*2007/46*0639*.. 55 - 75 185/65R15 744; 77E; 1); 2);
33)
Restrictions
744) The tightening torque of the custom wheels' fastening elements is specified in the vehicle's operating
manual. Should no tightening torque be specified there, the tightening torque quoted in the expert report
shall apply.
77E) The indirect Tire Pressure Monitoring system must be calibrated. The instructions of the manual must be
followed.
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
must be used.
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
