Anlage 9 - Verwendungsbereich
Prüfbericht 22-00174-CX-GBM-02
zur Erteilung der ECE (E1) 124R- 000832
ANLAGE: 9.1                                                            Radtyp: 16604108-30
Hersteller: MW Aftermarket Srl                                         Stand: 17.05.2022
______________________________________________________________________________________________________________
                                                                                                           Seite: 1 von 1

Manufacturer                             : PEUGEOT
Wheel dates:
Wheel size according to standard     : 6 J X 16 H2              Off set(mm)            : 27
Hole circle (mm)/number of holes     : 108/4                    centering type         : centering fixed
 Technical dates, short form
version           Version name                                       Centering Centering       Permis   Permiss     Valid
                                                                     hole      material        sible    ible        from
                                                                                               wheel    rolling
                  Wheel identification         Centering             (mm)                      Load     Circumf     Produ
                                               identification                                           erence      ction
                                                                                               (kg)     (mm)        date
R1-1640           R1-1640                      Without                        65                    500      1928     47/14
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer               : PEUGEOT
Mounting parts                           : conical collar bolt M12x1,25, tapered thread 60 Grad
Accessories                              : Serie
Tightening torque for fixing parts       : 90 Nm
 commercial type:         PEUGEOT 207
 Vehicle type Approval            kW       Tires                     Restrictions of tires     Restrictions
 W*****       e2*2001/116*0340*.. 66 - 88  205/55R16 91V                                       *); Front wheel
                                  66 - 128 195/55R16 87V                                       drive;
                                           195/55R16 91V                                       1); 2); 33)


*) The remarks under the listed restrictions/conditions are to be kept. If additional trademarks or sale- names are
listed, so there are only this vehicles permissible. All other vehicles to this one application are not concerned.
Restrictions

1)    To be kept:
      - the standard wheel size and offset.
      - tyre size with service description (load and speed index) and tyre brand commitments
      - as well as limitations to snow tyres (M+S) from the car documents.
      - requirements and limitations of snow chains from the operating licence and the operation manual.
2)    Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33)   The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
      must be used.




                                Benannt unter der Registriernummer KBA-P 00100-10
                  von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
