Anlage 9 - Verwendungsbereich
Prüfbericht 366-0074-16-WIRD
zur Erteilung der ECE (E1) 124R- 001045
ANLAGE: 9.2 Radtyp: 14605100-40
TUV AUSTRIA
Hersteller: MW Aftermarket Srl Stand: 25.02.2016
Seite: 1 von 2
Manufacturer : SEAT, SKODA, VOLKSWAGEN
Wheel dates:
Wheel size according to standard :6JX14 H2 Off set(mm) : 38
Hole circle (mm)/number of holes : 100/5 centering type : centering fixed
Technical dates, short form
version Version name Centering |Centering Permis (Permiss|Valid
hole material sible — е from
wheel |rolling
Wheel identification Centering (mm) Load |Circumf |Produ
identification erence |ction
(kg) (mm) |date
R1-1273 R1-1273 Without 57 505 1940| 4714
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : SEAT
Mounting parts : spherical collar bolt M14x1,5, diameter 26 mm
Tightening torque for fixing parts : 120 Nm
commercial type: SEAT TOLEDO/LEON
Vehicle type_|Approval KW Tires Restrictions of tires Restrictions
1M e9*97/27*0026*.. 50-74 |175/80R14 *); Front wheel
drive;
1); 2); 33)
1M e9*98/14*0026*.. 50-77 |175/80R14 1); 2); 33)
In built-up vehicle safety апа / ог environment-related vehicle systems (such аз tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : SKODA
Mounting parts : spherical collar bolt M14x1,5, diameter 26 mm
Tightening torque for fixing parts : 120 Nm
commercial type: SKODA OCTAVIA
Vehicle type_|Approval kW Tires Restrictions of tires Restrictions
1U e11*2001/116*0066*.. |55 175/80R14 88 1); 2); 33)
75 175/80R14 88H
1U e11*2007/46*0011*.. |55 175/80R14 88 1); 2); 33)
75 175/80R14 88H
1U e11*95/54*0066*.. — |44-92 |175/80R14 1); 2); 33)
In built-up vehicle safety апа / ог environment-related vehicle systems (such аз tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : VOLKSWAGEN
Mounting parts : spherical collar bolt M14x1,5, diameter 26 mm
Tightening torq ue for fixing parts : 120 Nm
Benannt unter der Registriernummer КВА-Р 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0074-16-WIRD
zur Erteilung der ECE (E1) 124R- 001045
ANLAGE: 9.2 Radtyp: 14605100-40
TUV
AUSTRIA
Hersteller: MW Aftermarket Srl Stand: 25.02.2016
Seite: 2 von 2
commercial tyı e: GOLF / BORA
Vehicle type |Approval KW Tires Restrictions of tires Restrictions
1J e172001/116*0071*.. |50-55 |175/80R14 88 *); Hatchback;
75-77 |175/80R14 88H Front wheel drive;
1); 2); 33)
1J е1*96/79*0071*.. 50-74 1|175/80R14 *); GOLF;
BORA(Limousine);
Limousine; Front
wheel drive;
1); 2); 33)
1J e1798/14*0071*.. 50-77 [175/80R14 1); 2); 33)
*) The remarks under №е listed restrictions/conditions are 10 be kept. Furthermore only the vehicles (trade name
or trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load апа speed index) апа tyre brand commitments
- а$ well а$ limitations to snow tyres (M+S) from the саг documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series-wheel
must be used.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
