Anlage 9 - Verwendungsbereich
TUV
Prüfbericht 366-0074-16-WIRD
zur Erteilung der ECE (E1) 124R- 001045
ANLAGE: 9.1 Radtyp: 1460510040 AUSTRIA
Hersteller: MW Aftermarket Srl Stand: 25.02.2016
Seite: 1 von 2
Manufacturer : SEAT, SKODA, VOLKSWAGEN
Wheel dates:
Wheel size according to standard :6JX14 H2 Off set(mm) :43
Hole circle (mm)/number of holes : 100/5 centering type : centering fixed
Technical dates, short form
version Version name Centering [Centering Permis [Permiss|Valid
hole material sible — е from
wheel |rolling
Wheel identification Centering (mm) Load |Circumf |Produ
identification erence |ction
(kg) (mm) |date
R1-1200 R1-1200 Without 57 508 1763| 47/14
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : SEAT
Mounting parts : spherical collar bolt M14x1,5, diameter 26 mm
Tightening torque for fixing parts : 120 Nm
commercial type: IBIZA,CORDOBA
\Vehicle type |Approval kW Tires Restrictions of tires Restrictions
6L e9*2001/116*0041*.. |44-63 |185/60R14 82 1); 2); 33)
44 -77 |185/60R14-82T
M+S
51-77 _ |185/60R14-82H
6L e9*98/14*0041*.. 47-55 |185/60R14 1); 2); 33)
47 -74 |185/60R14-82H
In built-up vehicle safety апа / ог environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : SKODA
Mounting parts : spherical collar bolt M14x1,5, diameter 26 mm
Tightening torque for fixing parts : 120 Nm
commercial type: FABIA
Vehicle type_|Approval kW Tires Restrictions of tires Restrictions
6Y е11*98/14*0123*.. 37-59 |185/60R14 82 1); 2); 33)
37-74 |185/60R14-82H
commercial type: FABIA PRAKTIK
Vehicle type |Approval kW Tires Restrictions of tires Restrictions
6Y L164 47 -51 [185/60R14 82 1); 2); 33)
In built-up vehicle safety and / or environment-related vehicle systems (such as tire pressure monitoring
systems) must remain functional or replaced.
Scope/Vehicle Manufacturer : VOLKSWAGEN
Mounting parts : spherical collar bolt M14x1,5, diameter 26 mm
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 366-0074-16-WIRD
zur Erteilung der ECE (E1) 124R- 001045
ANLAGE: 9.1 Radtyp: 14605100-40
TUV
AUSTRIA
Hersteller: MW Aftermarket Srl Stand: 25.02.2016
Seite: 2 von 2
Tightening torque for fixing parts : 120 Nm
commercial type: FOX
Vehicle type_|Approval kW Tires Restrictions of tires Restrictions
5Z e12001/116*0301*.. |40-55 [185/60R14 82 1); 2); 33)
185/60R14-82H
commercial type: VW POLO
Vehicle type_|Approval kW Tires Restrictions of tires Restrictions
9N e1*2001/116*0174*.. |40-63 _ [185/60R14 82 1); 2); 33)
74 185/60R14-82H
ON e172001/116*0174*.. |40-63 |185/60R14 82 *); from Nachtr.
74-77 |185/60R14-82H |е1*2001/116*0174*12;
1); 2); 33)
9N e1*98/14*0174*.. 40-74 [185/60R14 1); 2); 33)
*) The remarks under the listed restrictions/conditions аге to be kept. Furthermore only the vehicles (trade name
ог trademark listed in the conditions) are covered which are also listed in the field of applications.
Restrictions
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load апа speed index) апа tyre brand commitments
- as well аз limitations — Ю snow tyres (M+S) from the саг documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series-wheel
must be used.
Benannt unter der Registriernummer KBA-P 00055-00
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
