Anlage 9 - Verwendungsbereich
Prüfbericht 21-00028-CX-GBM-06
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000837
ANLAGE: 9.3 Radtyp: 15605100-41
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 1 von 5
Manufacturer : SEAT, SEAT, S.A., SKODA, VOLKSWAGEN
Wheel dates:
Wheel size according to standard : 6 J X 15 H2 Off set(mm) : 38
Hole circle (mm)/number of holes : 100/5 centering type : centering fixed
Technical dates, short form
version Version name Centering Centering Permis Permiss Valid
hole material sible ible from
wheel rolling
Wheel identification Centering (mm) Load Circumf Produ
identification erence ction
(kg) (mm) date
R1-1727 R1-1727 Without 57 500 1857 25/22
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : SEAT, SEAT, S.A.
Mounting parts : conical collar bolt M14x1,5, tapered thread 60 Grad
Tightening torque for fixing parts : 120 Nm
commercial type: IBIZA
Vehicle type Approval kW Tires Restrictions of tires Restrictions
6J e9*2001/116*0067*.. 55 - 81 185/60R15 *); from
55 - 110 185/60R15 M+S e9*2001/116*0067*32;
Station wagon;
Hatchback; Front
wheel drive;
744; 77E; BF3; 1);
2); 33)
6J e9*2001/116*0067*.. 132 185/60R15 88 744; 77E; BF3; 1);
185/60R15 88 2); 33)
M+S
6J e9*2001/116*0067*.. 132 185/60R15 88 744; 77E; 1); 2);
185/60R15 88 33)
M+S
6J e9*2001/116*0067*.. 44 - 110 185/60R15 744; 77E; 1); 2);
185/60R15 M+S 33)
59 175/65R15 84 ECO
66 - 77 175/65R15
132 185/60R15 88 from
e9*2001/116*0067*16
185/60R15 88 from
M+S e9*2001/116*0067*16
6J e9*2001/116*0067*.. 44 - 132 185/60R15 *); from
77 175/65R15 e9*2001/116*0067*21;
744; 77E; BF3; 1);
2); 33)
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 21-00028-CX-GBM-06
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000837
ANLAGE: 9.3 Radtyp: 15605100-41
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 2 von 5
commercial type: IBIZA
Vehicle type Approval kW Tires Restrictions of tires Restrictions
6J e9*2001/116*0067*.. 44 - 77 185/60R15 84 *); Not Fz with
77 175/65R15 84 "SeatSport"Bremse;
105 - 132 185/60R15 88 from
e9*2001/116*0067*21;
12K; 51G; 76W; 1);
2); 33)
6J e9*2001/116*0067*.. 44 - 110 185/60R15 *); only to
185/60R15 M+S e9*2001/116*0067*20;
55 - 77 175/65R15 12K; 51G; 76W; 1);
2); 33)
6J e9*2001/116*0067*.. 132 185/60R15 88 1); 2); 33)
185/60R15 88
M+S
commercial type: TOLEDO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
NH e11*2007/46*0251*.. 66 195/55R15 *); from
77 195/55R15 e11*2007/46*0251*01;
90 195/55R15 Limousine; Front
wheel drive;
12K; 51G; 76W; 1);
2); 33)
NH e11*2007/46*0251*.. 66 195/55R15 *); from
77 195/55R15 e11*2007/46*0251*01;
90 195/55R15 Limousine; Front
wheel drive;
744; BF3; 1); 2);
33)
NH e11*2007/46*0251*.. 55 - 92 185/60R15 *); from
66 - 90 195/55R15 e11*2007/46*0251*01;
66 - 92 185/60R15 M+S Front wheel drive;
12K; 51G; 76W; 1);
2); 33)
NH e11*2007/46*0251*.. 55 - 92 185/60R15 *); from
66 - 92 195/55R15 e11*2007/46*0251*01;
Limousine; Front
wheel drive;
744; BF3; 1); 2);
33)
NH e8*2007/46*0321*.. 70 - 92 185/60R15 744; 77E; 1); 2);
185/60R15 M+S 33)
NH e8*2007/46*0321*.. 70 - 92 185/60R15 744; 77E; BF3; 1);
185/60R15 M+S 2); 33)
Manufacturer : SEAT, SEAT, S.A., SKODA, VOLKSWAGEN
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : SKODA
Mounting parts : conical collar bolt M14x1,5, tapered thread 60 Grad
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 21-00028-CX-GBM-06
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000837
ANLAGE: 9.3 Radtyp: 15605100-41
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 3 von 5
Tightening torque for fixing parts : 120 Nm
commercial type: FABIA
Vehicle type Approval kW Tires Restrictions of tires Restrictions
5J e8*2007/46*0319*.. 44 - 92 185/60R15 744; 77E; BF3; 1);
185/60R15 M+S 2); 33)
195/55R15 M+S
5J e8*2007/46*0319*.. 44 - 92 185/60R15 12K; 51G; 76W; 77E;
185/60R15 M+S 1); 2); 33)
195/55R15 M+S
5J e8*2007/46*0319*.. 44 - 92 185/60R15 744; 77E; 1); 2);
185/60R15 M+S 33)
195/55R15 M+S
commercial type: PRAKTIK
Vehicle type Approval kW Tires Restrictions of tires Restrictions
5J N083 51 - 63 185/55R15 M+S 744; 1); 2); 33)
195/55R15
commercial type: RAPID
Vehicle type Approval kW Tires Restrictions of tires Restrictions
NH e11*2007/46*0250*.. 66 195/55R15 *); Front wheel
77 195/55R15 drive;
90 195/55R15 12K; 51G; 76W; 1);
2); 33)
NH e11*2007/46*0250*.. 55 - 92 185/60R15 *); RAPID
SPACEBACK;
66 - 92 195/55R15 Front wheel drive;
744; 1); 2); 33)
NH e11*2007/46*0250*.. 55 - 92 185/60R15 *); Front wheel
66 - 90 195/55R15 drive;
66 - 92 185/60R15 M+S 12K; 51G; 76W; 1);
2); 33)
NH e11*2007/46*0250*.. 55 - 92 185/60R15 *); Limousine;
66 - 92 195/55R15 Front wheel drive;
744; 1); 2); 33)
NH e8*2007/46*0320*.. 66 - 92 185/60R15 12K; 51G; 76W; 77E;
185/60R15 M+S 1); 2); 33)
commercial type: ROOMSTER, FABIA, PRAKTIK
Vehicle type Approval kW Tires Restrictions of tires Restrictions
5J e11*2001/116*0291*.. 44 - 77 185/55R15 M+S 12K; 51G; 76W; 1);
185/60R15 2); 33)
195/55R15
5J e11*2001/116*0291*.. 44 - 81 185/60R15 *); from
e11*2001/116*0291*26;
12K; 51G; 76W; 1); 2);
33)
5J e11*2001/116*0291*.. 44 - 81 185/60R15 744; BF3; 1); 2);
33)
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 21-00028-CX-GBM-06
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000837
ANLAGE: 9.3 Radtyp: 15605100-41
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 4 von 5
commercial type: ROOMSTER, FABIA, PRAKTIK
Vehicle type Approval kW Tires Restrictions of tires Restrictions
5J e11*2001/116*0291*.. 44 - 77 185/55R15 M+S *); only to
195/55R15 85H e11*2001/116*0291*25;
744; BF3; 1); 2); 33)
5J e11*2007/46*0013*.. 77 195/55R15 85H *); Fabia station
wagon; Scout;
12K; 51G; 76W; 1);
2); 33)
5J e11*2007/46*0013*.. 44 - 81 185/60R15 12K; 51G; 76W; 1);
2); 33)
5J e11*2007/46*0013*.. 44 - 81 185/60R15 744; 1); 2); 33)
Manufacturer : SEAT, SEAT, S.A., SKODA, VOLKSWAGEN
Prescribed systems in the vehicle must be functioning with the use of the described rim combination.
Scope/Vehicle Manufacturer : VOLKSWAGEN
Mounting parts : conical collar bolt M14x1,5, tapered thread 60 Grad,
for Type : 6R
Accessories : Serie
Mounting parts : conical collar bolt M14x1,5, tapered thread 60 Grad,
for Type : 6R; 9N
Tightening torque for fixing parts : 120 Nm
commercial type: POLO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
6R e1*2001/116*0510*.. 44 - 103 185/60R15 744; BF3; 1); 2);
77 - 103 175/65R15 33)
110 185/60R15 M+S
6R e1*2001/116*0510*.. 132 185/60R15 M+S 12K; 51G; 76W; 1);
2); 33)
6R e1*2001/116*0510*.. 44 - 103 185/60R15 12K; 51G; 76W; 1);
77 - 103 175/65R15 2); 33)
110 185/60R15 M+S
6R e1*2001/116*0510*.. 44 - 77 185/60R15 744; 1); 2); 33)
6R e1*2001/116*0510*.. 132 185/60R15 M+S 744; BF3; 1); 2);
33)
6R e1*2001/116*0510*.. 44 - 103 185/60R15 12K; 51G; 76W; 1);
55 - 132 185/60R15 M+S 2); 33)
77 - 103 175/65R15
6R e1*2007/46*0486*.. 44 - 81 185/60R15 744; BF3; 1); 2);
110 185/60R15 M+S 33)
6R e1*2007/46*0486*.. 44 - 81 185/60R15 12K; 51G; 76W; 1);
110 185/60R15 M+S 2); 33)
6R e1*2007/46*0486*.. 44 - 77 185/60R15 84 12K; 51G; 76W; 1);
77 185/60R15 84H 2); 33)
6R e1*2007/46*0486*.. 51 - 77 185/60R15 12K; 51G; 76W; 1);
2); 33)
Benannt unter der Registriernummer KBA-P 00100-10
von der Benennungsstelle des Kraftfahrt-Bundesamtes, Bundesrepublik Deutschland.
Anlage 9 - Verwendungsbereich
Prüfbericht 21-00028-CX-GBM-06
zur Erteilung eines Nachtrags zur ECE (E1) 124R- 000837
ANLAGE: 9.3 Radtyp: 15605100-41
Hersteller: MW Aftermarket Srl Stand: 29.09.2022
______________________________________________________________________________________________________________
Seite: 5 von 5
commercial type: VW POLO
Vehicle type Approval kW Tires Restrictions of tires Restrictions
9N e1*2001/116*0174*.. 40 - 77 185/60R15 84 *); Polo-Fun; Polo-
Cross;
12K; 51G; 76W; 1);
2); 33)
*) The remarks under the listed restrictions/conditions are to be kept. If additional trademarks or sale- names are
listed, so there are only this vehicles permissible. All other vehicles to this one application are not concerned.
Restrictions
12K) The use of snow chains is only permitted if the latter have been approved by the vehicle manufacturer for
this wheel/tire combination (cf. operating instructions).
51G) This wheel/tire combination may only be used if this tire has already been entered as the standard in
vehicle documents or has been approved by the vehicle manufacturer, see excerpts from EC vehicle
approval (EC certificate of compliance). The load index, speed symbol, M+ S identification, the tire makes
entered in the vehicle documentation and the remarks and recommendations of the vehicle manufacturer
must be observed when this tire size is used.
744) The tightening torque of the custom wheels' fastening elements is specified in the vehicle's operating
manual. Should no tightening torque be specified there, the tightening torque quoted in the expert report
shall apply.
76W) The use of this wheel/tire combination is only permitted if this wheel/tire combination has been entered by
the vehicle manufacturer in the vehicle documents already.
77E) The indirect Tire Pressure Monitoring system must be calibrated. The instructions of the manual must be
followed.
BF3) The use of the wheels is not permitted on vehicle versions with brake disc diameter 310mm or larger on
the front axle.
1) To be kept:
- the standard wheel size and offset.
- tyre size with service description (load and speed index) and tyre brand commitments
- as well as limitations to snow tyres (M+S) from the car documents.
- requirements and limitations of snow chains from the operating licence and the operation manual.
2) Only permissible at vehicle models, which are allowed to use steel wheels as standard.
33) The standard fixing parts and accessories of the vehicle manufacturer for the corresponding series -wheel
must be used.
