Quality Test Report                      Report No.:
                                                                             0173/20/01

                                  Declaration of conformity                    Page 1/2



                                                                  Manno, 15 September 2020




Alcar Ruote SA declares that the wheel 0173 is conform to the requirements of EUWA
STANDARD ES 3.10 for the use of vehicles with a carrying capacity of 710 Kg.

Below are the test results confirming the requested specifications:

                                        Wheel Data
                          Wheel No:                    0173
                        Wheel Dimension:             13 x 4.5 J




                    FATIGUE TEST: ROTARY BENDING
The test has been done according to the EUWA STANDARDS ES 3.10


                                                         According to EUWA Agricultural
                               Test Specification acc:
                                                                    ES 3.10
                               Testing moment M1:                  3.034 kNm
                       Required no. of rotations R1:             20’000 cycles
                               Testing moment M2:                  2.023 kNm
                       Required no. of rotations R2:             233’000 cycles
                                          Used bolts:              M14 x 1.5
      Fixing moment of wheel bolts or attaching nuts:                120 Nm
                              Production date Disc:                   28/20
                              Production date Rim:                    29/20
                                        RESULT:
                         Test result sample 1 (M1):            25‘000 Stop no crack
                         Test result sample 2 (M1):            25‘000 Stop no crack
                         Test result sample 3 (M2):           300‘000 Stop no crack
                         Test result sample 4 (M2):           300‘000 Stop no crack
                                    Quality Test Report                       Report No.:
                                                                              0173/20/01

                                  Declaration of conformity                    Page 2/2

                   FATIGUE TEST: DYNAMIC RADIAL
The test has been done following the EUWA STANDARDS ES 3.10

                                                             According to EUWA
                             Test Specification acc. To:
                                                                  ES 3.10
                                  Testing load radial FR:         13.93 kN
                                 Required no. of rot. R:           555‘000
                                             Used Tire :          165 R13C
                                      max. air pressure:           4.5 bar
                                            Used bolts :          M12 x 1.5
         Fixing moment of wheel bolts or attaching nuts:           120 Nm
                                Production date Disc:              28/20
                                Production date Rim:               29/20
                                            RESULT:
                                Test result sample 1:       800‘000 Stop no crack
                                Test result sample 2:       800‘000 Stop no crack



                                                              Inspector:
                                                              Luca Drera
