MW Aftermarket srl


  Document nr.           WCD08-2023                                                                        03/04/2023


                                     Wheel Conformity Declaration


Find below the wheel conformity guidelines in terms of loading and corrosion protection.
This indication is valid only for the application indicated below.
Any other applications and performances are highly forbidden. In case of other usage or
different conformity declaration ask to MW Aftermarket, giving all the necessary data.



                        Wheel p/n:          R1-1427 rev.02

                      Description:          5J x 13H2        Offset33        5x112 spherical


                                                              Max Vehicle                 Max Load
                            Application
                                                              Speed [km/h]               Capacity [kg]

                    CAR TRAILER WHEEL                                140                       725

The wheel load capacity has been defined in accordance with the regulation StVZO and ECE
R124 (ref Capt. 6 Paragr.6.5.1 Annexes 6 - 7) for steel wheels and vehicle categories O1-O2.


                     Corrosion protection                            UNI EN ISO 9227 NSS 600h



The above Corrosion Protection has been defined in accordance with the UNI EN ISO
9227 NSS 600h as commonly used for vehicle and trailer market.
Conformity released by internal reports: Rdl 598-22; Rdl209/22.


Attention: the wheel is a highly stressed component that in service may be subjected
to extreme forces. Improper usage (different application, higher load or higher speed than
the above stated ones) may lead to reduce the life performance with the generation of
fatigue cracks that may eventually result in part separation (risks of wheel detachment
from the vehicle).

Please procure and read carefully the following recommendations:

EUWA Safety and Service Recommendations
https://www.euwa.org/resources/type/safety-information/


These information should be forwarded to your final customer to prevent risks of accident
due to any action not in compliance with these guidelines.


              Best regards,                                                          MW Aftermarket srl
                                                                                     Engineering/Quality
