DIPARTIMENTO PER LA MOBILITA' SOSTENIBILE
DIREZIONE GENERALE TERRITORIALE DEL NORD - OVEST
UFFICIO 8 - CENTRO PROVA AUTOVEICOLI @& MILANO e sezione coordinata di BRESCIA
Comunicazione riguardante / Communication conceming
di-omeolk - granied
- V’estensione dell’omologazione
/ approval extended
-del’omelo йн
Di un tipo di ruota @ sostituzione o dei componenti di questo sistema conforme al Regolamento №124 Emendamento № 01 айа serie 00. Supplemento 01
Ога type of Wheel ог components of the said system pursuantto Regulation №124 Emendment No 01 series 00. Supplement 01
Estensione №:
Omologazione N° / Approval №: 124R00/01*3187 Exensont 02
Marcatura ruota / Wheel marking E3 124R-013187
Fabbricante della ruota:
(Wheel Manufacturer) Fondmetal S.p.A.
Designazione del tipo di ruota:
(Wheel type designation) FMI069019
Categoria delle ruote sostitutive: Ruote sostitutive replica parziale (def. 2.4.4)
21
(Category of replacement wheels) Pattern part replacement wheels (def. 2.4.4)
Materiali impiegati
22 AISi 10 Си
(Construction material)
23
Metodo di Produzione: Fusione in gravitä
(Method of production) Gravity casting
24
Designazione del profili del cerchio 9.0
Jx 19" Н2
(Rim contour designation)
25
Off-set della ruota: Vedere LISTA APPLICAZIONI (Allegato 1)
(Wheel inset) See FITMENT LIST (Attachment 1)
26
Fissaggio della ruota 5 (Cinque) Fori
(Wneel attachment) 5 (Five) Holes
27
Portata Massima e circonferenza di rotolamento 950 Ка 2410mm ог ET20/33/44/45
(Maximum wheel load апа respective theoretical rolling circumference) 900 Ка 2300mm for ET58
Indirizzo del fabbricante: Via Bergamo, 4 - 24050 - Palosco (italy)
(Manufacturer's address)
Se del caso, nome e indirizzo del rappresentante del fabbricante:
(If applicable, name апа address of manufacturer's representative)
Data @ presentazione della ruota per 1е prove @ omologazione: 02/11/2022
(Wheel submission date for approval test)
Imposta di BOLLO assolta in modo virtuale Рад. 1/2
124R00/01*3187 Estensione № / Extension №: 02
Servizio tecnico incaricato dellesecuzione delle prove di
omologazione: UFFICIO 8 - CENTRO PROVA AUTOVEICOLIdi MILANO е sezione coordinata di
BRESCIA
(Technical Service responsible for carrying out the approval test)
Data del verbale di prova stilato: 06/05/2020 | 13111120 | 221112022
(date of test report issued by the Technical Service)
Митего del Verbale @ prova stilato dal servizio tecnico: 45341V-BS | 46378IV-BS | 51628/V-BS
(Number of test report issued by the Technical Service)
Osservazioni
(Remarks)
L'omologazione ё rilasciata #ifiutatalestesalrevecata: Rilasciata
(Approval granted /refusediexiendediwithdrawn) Granted
Se del caso, motivi dellestensione Aggiunta versione ET58 5x112 e aggiornata lista applicazioni
(Reason(s) for the extension (if applicable) ) Added 5x112 ЕТ58 version апа fitment list updating
Luogo: Brescia
(Place)
Data:
(Date)
Firma/ Nome: Visto: II Direttore dell'Ufficio
(Signature/ Name) Tug. Autouclle Pervao
Antonello Persano
MiMs
10.01.2023 12:37:39
— GMT+01:00
Allegati: LISTA APPLICAZIONI/ FITMENT LIST - Scheda informativa
(ALLEGATO 1) e I'NDICE DEL FASCICOLO - elenco dei Information Document
documenti che costituiscono il dossier delfomologazione e che
sono depositati presso Autorita che ha rilasciato 'omologazione. - Istruzioni & montaggio
Una copia dei documenti puö essere ottenuta su richiesta Fitting instructions
FMI069019_rev02
Аппехез: - Accessori
LISTA APPLICAZIONI/ FITMENT LIST (ALLEGATO 1) апа Acessories
INDICE DEL FASCICOLO - List of documents making ир the
approval file, deposited with the competent Authority which granted Disegni
-
approval, a copy can be obtained on request. Drawings
Imposta di BOLLO assolta in modo virtuale Pag.2/2
LISTA APPLICAZIONI / FITMENT LIST (ALLEGA E3 124R-013187*02
Mnistors L. уеаг в dei hagfiords Visto: И Direttore dell'Ufficio
DIPARTIMENTO PER LA MOBILITA' SOSTENIBILE Ty, Autonello Persans
DIREZIONE GENERALE TERRITORIALE DEL NORD - OVEST Documento firmato digitalmente
UFFICIO 8 - CENTRO PROVA AUTOVEICOLI di MILANO e sezione coordinata di BRESCIA Digitally signed document
Caa Omologazione globale Vite /Dado| _ Pneumatico е
ostruttore
3.1.3. | penominazione Commerciale 3.1.3. Europea Codice del Cerchio 19728901
3.1.2.5 realtive
иа note
3.1.3. 3.1.2.12.
Manufacturer | ее | е Eu Homologation Tyre
e1*2001/116*0430*.
Audi АБ / $5 2007 | 2012 | В8 |е1*2001/116*0447*.. РМ1069019 335112 | 5x112 | 66.5 33 - 0V.VO40 | OE255/35R19 S5 included
е13*2007/46*1084"..
е1*2001/116*0430°..
Audi АБ / $5 2013 2016 — B8 — е1*2001/116*0447*. FMI069019 33 5112 5x112 66.5 33 - — 0V.VO40 OE 255/35 В19 — $5 included
е13*2007/46*1084".
Audi й А8 / $8 2010 2017 | 4Н е1*2007/46*0284*...
©“д007/46ОЗоВ* FMI069019 335112 | 5x112 | 66.5 33 - | OV.VO40 | ОЕ 255/45 R19 S8 included
Ford Mustang (MK6) 2015 LAE e13*2007/46*1551*. FMI069019 45 5114B 5x114.3 70.4 45 - OENUT OE 255/40 R19
Only rear axle
Mercedes-Benz AMG GLC 43 2016 204X e1*2001/116*0480*. РМ1069019 205112 5x112 66.5 20 - 0V.VO40 | ОЕ 255/50 В19 Only in combination with FMI068019
OE CAP Ready
GLC Coupe Only rear axle
Mercedes-Benz (С253) 2016 204 e1*2001/116*0480*.. FMI069019 20 5112 5x112 665 20 - — 0V.VO40 OE 255/50 В19
Only in combination with FMI068019
ОЕ САР Ready
Volkswagen — 0. BUZZ 2022 ЕВ — |е1*2018/858*00164*..
ЕВМ e1"2018/858*00165* | FMI06901958 5112L | 5x112 | 57.1 | 58 - | OEBOLT | ОЕ 255/50 R19 | only
Lot rear,
o only
o infrontcombination
axle with
CONDIZIONI e NOTE GENERALI / GENERIC CONDITION апа NOTE
NOTA PRELIMINARE Solo se indicato come equipaggiamento originale (previsto dal costruttore) sulla carta di circolazione del veicolo.
PRELIMINARY NOTE Only # mentioned ав original equipment (allowed by vehicle manufacturer) on the vehicle documents.
CATENABILITA In merito айа catenabilita delle configurazioni indicate fare riferimento alle prescrizioni del costruttore del veicolo.
CHAINABILITY For the chainability of the listed configurations, please refer 10 the vehicle manufacturer's prescriptions.
In caso di bulloneria originale del costruttore del veicolo utilizzare 1а coppia di serraggio prevista dallo stesso costruttore del veicolo.
BULLONERIA - COPPIA DI SERRAGGIO In caso di bulloneria aftermarket fornita da FONDMETAL S.p.A. fare riferiemnto айа prescrizioni di montaggio indicate nell'apposito opuscolo informativo allinterno della
scatola ruota.
BOLT TIGHTENING TORQUE
In the case о! original bolts/nuts, please follow the vehicle manufacturer's tightening torque recommendations.
In the case о! aftermarket bolts/nuts supplied by FONDMETAL S.p.A., please make reference to the prescriptions in the leaflet supplied with the wheel.
PRESSIONE PNEUMATICI CONSIGLIATA
Fare riferimento alle prescrizioni del costruttore del veicolo normalmente riportate tramite etichette sulle portiere, о all’interno del tappo della benzina o riportate sul
manuale uso e istruzioni
e B/ TS R Please make reference to the vehicle manufacturer's recommendations, which аге normally specified through labels on the vehicle doors or inside the petrol tank plug, ог
mentioned in the vehicle instructions manual.
COMPATIBILITA' TPMS Fare riferimento айа specifica FONDMETAL - TPMS Compatibility
TPMS COMPATIBILITY Please make reference 10 the speficic FONDMETAL - TPMS Compatibility
Pag. 1 di 1
