Certificate on ECE R124 000756
Annex 5 to Test report Nr. 55807714 (1st release)
Test object Wheel for passenger cars 6,0J x 15EH2+ Type 702
Manufacturer MOMO Srl
Page 1 of 2
Test object
Version Wheel Marking / Center-ring Number of holes / Offset Whee Rolling
PCD- (mm)/ (mm) l load circumferenc
Center hole-ø (kg) e (mm)
(mm)
D7 702-D7 4/100/60,1 40 480 1894
Fixing element
Nr. Type of fixing element Seat Fixing torque (Nm) Shaft length (mm)
S01 Original equipment screw Conical 60° 105 23,5
M12x1,5
Application
Trade name kW-range Tire Tire-related conditions and notes Conditions
Vehicle type and notes
Approval number
Dacia Sandero (II) 53, 55, 66 185/65R15 A13 A14 A18
SD/SR (5SD../5SR..) A58 ECE Flh
e2*2001/116* S01
0314*58-..;0323*29-..;
e2*2007/46*0030*20-..
Renault Clio (IV) 48-66 185/65R15 M+S A11 A14 A18
R 48-66 185/65R15 A58 Car ECE
e2*2001/116* Flh RC4 S01
0327*46-..;
e2*2007/46*0008*16-..
General information
The minimum required speed ranges (with the exception of the M + S profiles) and carrying capacities
to be used for tires are reported in the vehicle documents (vehicle registration certificate).
Furthermore, only one tire type on the same axle is permitted. When using different types of tires on
front and rear axle, it should be according to the notes of the vehicle and / or tire manufacturer's
instructions.
The suspension and brake components shall comply with the exception of retrofit measures applied in
the appropriate edition, as original equipment. The admissibility of further changes must be assessed
separately.
The standard spare wheel must not be used for longer distance than necessary, always at moderate
speed and using the standard equipment. On vehicles with all-wheel drive, only one spare tire with the
same size and the same rolling circumference of original tire size may be used.
The users of the wheels must be informed that the tire pressure prescribed by the tire manufacturer
must be observed.
TUV Rheinland Italia – Via Mattei, 3 – 20010 Pogliano Milanese (MI)
Certificate on ECE R124 000756
Annex 5 to Test report Nr. 55807714 (1st release)
Test object Wheel for passenger cars 6,0J x 15EH2+ Type 702
Manufacturer MOMO Srl
Page 2 of 2
Special conditions and notes
A11 Only fine-linked snow chains may be used at the drive axle.
A13 Only fine-linked snow chains may be used at the front axle.
A14 Only adhesive weights may be affixed to the exterior of the rim below the bead seat for
balancing the special wheels.
A18 Only tubeless tyres and metal screw-on valves mounted from outside and in broad conformity
with the DIN, E.T.R.T.O or "Tire and Rim" standard are permissible.
A58 Wheel/tyre combination(s) is (are) not permissible on vehicles with all-wheel drive.
Car The wheel/tyre combination is permissible for vehicle models of the Avant, Caravan, estate-
car and/or touring variants.
ECE The use of this wheel / tire combination is permissible only if these tires are already registered
as standard equipment in the vehicle documents or released by the vehicle manufacturer, see extract
from the EC type-approval of the vehicle (EC certificate of conformity). The load index, speed symbol,
the M + S designation, the tire manufacturer and the advices/recommendations reported in
documentation of the vehicle manufacturer must be respected when using this tire size
Flh The wheel/tyre combination is permissible for hatchback vehicle models, both with 3 and 5
doors.
M+S This tyre size is only permissible as mud and snow tyres.
th th
RC4 The wheel/tyre combination is intended for Renault Clio IV (4 and 5 position of VIN equal to
5R, 6R or 7R).
S01 For fastening the special wheels only original equipment fixing element no. S01 (see page 1)
can be used.
00222265.DOC
TUV Rheinland Italia – Via Mattei, 3 – 20010 Pogliano Milanese (MI)
