Certificate on ECE R124 000756
Annex 2 to Test report Nr. 55807714 (1st release)
Test object Wheel for passenger cars 6,0J x 15EH2+ Type 702
Manufacturer MOMO Srl
Page 1 of 2
Test object
Version Wheel Marking / Center-ring Number of holes / Offset Whee Rolling
PCD- (mm)/ (mm) l load circumferenc
Center hole-ø (kg) e (mm)
(mm)
D4 702-D4 4/100/60,1 43 550 1894
Fixing element
Nr. Type of fixing element Seat Fixing torque (Nm) Shaft length (mm)
S01 Original equipment screw Conical 60° 100 25,5
M12x1,5
S02 Original equipment screw Conical 60° 105 23,5
M12x1,5
Application
Trade name kW-range Tire Tire-related conditions and notes Conditions
Vehicle type and notes
Approval number
Dacia Logan 50-77 185/65R15 A31 ECE A14 A18 Sth
SD/SR S02
e2*2001/116*
0314*00-61;
0323*00-29;
e2*2007/46*0030*..;
e2*2007/46*0013*..
Dacia Logan MCV 50-77 185/65R15 A11 ECE A14 A18 Car
SD/SR S02
e2*2001/116*
0314*00-61;
0323*00-29;
e2*2007/46*0030*..;
e2*2007/46*0013*..
- Kombi
Renault Clio (III) 48-102 185/60R15 A31 ECE A14 A18 B03
R Car Flh R1S
e2*2001/116*0327*..; RC3 S01
e2*2007/46*0008*..
Renault Clio (III) 48-102 185/60R15 A11 ECE A14 A18 B03
R Car Flh R1B
e2*2001/116*0327*..; RC3 S01
e2*2007/46*0008*..
General information
The minimum required speed ranges (with the exception of the M + S profiles) and carrying capacities
to be used for tires are reported in the vehicle documents (vehicle registration certificate).
Furthermore, only one tire type on the same axle is permitted. When using different types of tires on
front and rear axle, it should be according to the notes of the vehicle and / or tire manufacturer's
instructions.
TUV Rheinland Italia – Via Mattei, 3 – 20010 Pogliano Milanese (MI)
Certificate on ECE R124 000756
Annex 2 to Test report Nr. 55807714 (1st release)
Test object Wheel for passenger cars 6,0J x 15EH2+ Type 702
Manufacturer MOMO Srl
Page 2 of 2
The suspension and brake components shall comply with the exception of retrofit measures applied in
the appropriate edition, as original equipment. The admissibility of further changes must be assessed
separately.
The standard spare wheel must not be used for longer distance than necessary, always at moderate
speed and using the standard equipment. On vehicles with all-wheel drive, only one spare tire with the
same size and the same rolling circumference of original tire size may be used.
The users of the wheels must be informed that the tire pressure prescribed by the tire manufacturer
must be observed.
Special conditions and notes
A11 Only fine-linked snow chains may be used at the drive axle.
A14 Only adhesive weights may be affixed to the exterior of the rim below the bead seat for
balancing the special wheels.
A18 Only tubeless tyres and metal screw-on valves mounted from outside and in broad conformity
with the DIN, E.T.R.T.O or "Tire and Rim" standard are permissible.
A31 Only fine-linked snow chains, which come to an overall thickness of not more than 12 mm
(including chain joint), may be used at the drive axle.
B03 The special wheels are not permissible on vehicles which are equipped exclusively with larger
and/or wider standard wheels (with the exception of rims for mud and snow tyres).
Car The wheel/tyre combination is permissible for vehicle models of the Avant, Caravan, estate-
car and/or touring variants.
ECE The use of this wheel / tire combination is permissible only if these tires are already registered
as standard equipment in the vehicle documents or released by the vehicle manufacturer, see extract
from the EC type-approval of the vehicle (EC certificate of conformity). The load index, speed symbol,
the M + S designation, the tire manufacturer and the advices/recommendations reported in
documentation of the vehicle manufacturer must be respected when using this tire size
Flh The wheel/tyre combination is permissible for hatchback vehicle models, both with 3 and 5
doors.
R1B The whee/tyre combination is permissible only for vehicle models with wide wheelarches on
front axle and narrow track on rear axle (6th position of VIN equal to A, C, F, H, R or 6)
R1S The whee/tyre combination is permissible only for vehicle models with wide track on rear axle
(6th position of VIN equal to 1, 2, 3, 4, D, E, L or S).
th th
RC3 The whee/tyre combination is permissible only for Reanult Clio III (4 and 5 position of VIN
equal to BR, CR, KR or SR).
S01 For fastening the special wheels only original equipment fixing element no. S01 (see page 1)
can be used.
S02 For fastening the special wheels only original equipment fixing element no. S02 (see page 1)
can be used.
Sth The wheel/tyre combination is permissible for vehicle models of the notchback variant.
00221615.DOC
TUV Rheinland Italia – Via Mattei, 3 – 20010 Pogliano Milanese (MI)
