Ministero delle infrastrutture e dei trasporti
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA
Comunicazione riguardante / Communication concerning
E3
- concessione di omologazione / approval granted
- l’estensione dell’omologazione / approval extended
- il rifiuto dell’omologazione / approval refused
- la revoca dell’omologazione / approval withdrawn
- cessazione definitiva della produzione / production definitely
Di un tipo di ruota di sostituzione o dei componenti di questo sistema conforme al Regolamento N°124 Emendamento No 04 alla serie 00. Supplemento 04.
Of a type of Wheel or components of the said system pursuant to Regulation N°124 Emendment No 04 series 00. Supplement 04
Estensione N°:
Omologazione N° / Approval N°: 124R00/04*3198 Extension N°: 06
Marcatura ruota / Wheel marking : E3 124R-013198
Fabbricante della ruota:
1
(Wheel Manufacturer)
Fondmetal S.p.A.
Designazione del tipo di ruota:
2
(Wheel type designation)
WI238519
Categoria delle ruote sostitutive: Ruote sostitutive replica parziale (def. 2.4.4)
2.1
(Category of replacement wheels) Pattern part replacement wheels (def. 2.4.4)
Materiali impiegati:
2.2 AlSi 10 Cu
(Construction material)
Metodo di Produzione: Fusione in gravità
2.3
(Method of production) Gravity Casting
Designazione del profili del cerchio:
2.4 8.5 J x 19" H2
(Rim contour designation)
Off-set della ruota: Vedere LISTA APPLICAZIONI (Allegato 1)
2.5
(Wheel inset/outset) See FITMENT LIST (Attachment 1)
Fissaggio della ruota: 5 (Cinque) fori
2.6
(Wheel attachment) 5 (Five) holes
Portata Massima e circonferenza di rotolamento:
2.7 905 Kg 2400mm
(Maximum wheel load and respective theoretical rolling circumference)
Indirizzo del fabbricante:
3 Via Bergamo, 4 - 24050 - Palosco (Italy)
(Manufacturer's address)
Se del caso, nome e indirizzo del rappresentante del fabbricante: -
4
(If applicable, name and address of manufacturer's representative)
-
Data di presentazione della ruota per le prove di omologazione:
5 11/07/2025
(Wheel submission date for approval test)
Imposta di BOLLO assolta in modo virtuale Pag. 1 / 2
124R00/04*3198 Estensione N° / Extension N°: 06
Servizio tecnico incaricato dell'esecuzione delle prove di
omologazione:
6 Centro Prova Autoveicoli di MILANO con sezione di BRESCIA
(Technical Service responsible for carrying out the approval test)
Data del verbale di prova stilato: 19/11/ 02/08 14/12 26/03 19/09 26/03 17/07
7
(date of test report issued by the Technical Service) 2020 2021 2023 2024 2024 2025 2025
Numero del Verbale di prova stilato dal servizio tecnico: 46400 48181 54368 55151 56458 58055 58872
8
(Number of test report issued by the Technical Service) V-BS V-BS V-BS V-BS V-BS V-BS V-BS
Osservazioni: Per ragioni di opportunità la marcatura non è stata modificata
9
(Remarks) For expediency reasons the marking has not been changed
10
L'omologazione è rilasciata /rifiutata/estesa/revocata: Estesa
(Approval granted / refused/extended/withdrawn) Extended
Aggiunte versioni ET29 5x112 R, ET38 5x112 L e ET56 5x108 F e
11 Se del caso, motivi dell'estensione:
relative applicazione
Added versions ET29 5x112 R, ET38 5x112 L and
(Reason(s) for the extension (if applicable) )
ET56 5x108 F and its fitments
12 Luogo:
Brescia
(Place)
13 Data:
(Date)
AC D
GE
14 Firma/ Nome:
Il Dirigente I I I
(Signature/ Name) H LH
I HII
Allegati: - Scheda informativa
LISTA APPLICAZIONI / FITMENT LIST
Information Document
(ALLEGATO 1) e l'INDICE DEL FASCICOLO - elenco dei
documenti che costituiscono il dossier dell'omologazione e che
- Istruzioni di montaggio
sono depositati presso l'Autorità che ha rilasciato l'omologazione.
Una copia dei documenti può essere ottenuta su richiesta Fitting instructions
15 WI238519_rev07
Annexes: - Accessori
LISTA APPLICAZIONI / FITMENT LIST (ALLEGATO 1) and INDICE DEL Acessories
FASCICOLO - List of documents making up the approval file, deposited
with the competent Authority which granted approval, a copy can be - Disegni
obtained on request.
Drawings
Imposta di BOLLO assolta in modo virtuale Pag. 2 / 2
Approval n°: E3 124R-00/04*3198*06
LISTA APPLICAZIONI / FITMENT LIST (ALLEGATO 1)
Wheel marking: E3 124R-013198
Ministero delle infrastrutture e dei trasporti Il Dirigente
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
e-tron / e-tron
Audi 2019 2023 GE e1*2007/46*1914*.. WI238519 36_5_112P 5x112 66.5 36 - OE BOLT OE 255/55 R19
Sportback
Q3 (MK3) / Q3
Audi 2025 FJ e1*2018/858*00543*.. WI238519 38_5_112L 5x112 57.1 38 - OE BOLT OE 255/45 R19
Sportback
Audi Q8 e-tron 2023 GE e1*2007/46*1914*.. WI238519 36_5_112P 5x112 66.5 36 - OE BOLT OE 255/55 R19
WI238519 29_5_112R 5x112 66.5 29 - OE BOLT OE 245/45 R 19 only limousine/berlina
BMW i5 G60 2023 G6E e1*2018/858*00317*..
only front, only station wagon /
WI238519 29_5_112R 5x112 66.5 29 - OE BOLT OE 245/45 R 19
Touring
BMW X3 G45 2024 G3XN e1*2018/858*00409*.. WI238519 26_5_112R 5x112 66.5 26 - OE BOLT OE 245/50 R19
e1*2018/858*00316*..
BMW Serie 5 G60/61 2023 G6L, G6K WI238519 29_5_112R 5x112 66.5 29 - OE BOLT OE 245/45 R 19 no M Sport brake (20")
e1*2018/858*00360*..
BYD Sealion 7 2024 UK e9*2018/858*11658*.. WI238519 40_5_120 5x120 64.1 40 - OE NUT OE 255/45 R 19 only rear, only RWD
38_5_112M 5x112 57.1 38 - OE BOLT OE 255/45 R19 FM D.64mm CAP seat
CUPRA (Seat) Terramar 2024 KP e9*2018/858*04014*.. WI238519
38_5_112M1 5x112 57.1 38 - OE BOLT OE 255/45 R19 OE D.57mm Cupra/Seat CAP seat
Ford Capri 2025 DRP e1*2018/858*00364*.. WI238519 40_5_112M 5x112 57.1 40 OE BOLT OE 255/50 R 19 only rear
Ford Explorer UE 2024 DRP e1*2018/858*00364*.. WI238519 40_5_112M 5x112 57.1 40 OE BOLT OE 255/50 R 19 only rear
E-Classe R2EW, e1*2018/858/00213*..
Mercedes-Benz 2024 WI238519 35_5_112S 5x112 66.5 35.5 - OE BOLT OE 245/45 R19 only front
(W214) R2ES e1*2018/858/00214*..
Marvel / RX7 / R
MG Electric / X 2022 EP21 e4*2018/858*00004*.. WI238519 50_5_120 5x120 67.1 50 - OE NUT OE 235/45 R19
Electric
Pag. 1 di 2
Ministero delle infrastrutture e dei trasporti Il Dirigente
Dipartimento per i Trasporti e la Navigazione
Direzione Generale Territoriale del Nord-Ovest Documento firmato digitalmente
Centro Prova Autoveicoli di MILANO con sezione di BRESCIA Digitally signed document
Omologazione globale Pneumatico e
Anello
Costruttore Tipo Centra Offset Vite / Dado
Denominazione Commerciale 3.1.3. Europea Codice del Cerchio PCD realtive note Note
3.1.3. 3.1.3. ggio 3.1.2.2 3.1.2.5
3.1.3. 3.1.2.12.
Manufacturer Car model From 2019 Type Eu Homologation Wheel part number C.B. ET Rings Bolt / Nut Tyre Note
Volkswagen ID.7 2023 ED e1*2018/858*00306*.. WI238519 42_5_112M 5x112 57.1 42 - OE BOLT OE 255/45 R19 only rear
Volkswagen Tayron 2024 R4 e1*2018/858*00403*.. WI238519 38_5_112M 5x112 57.1 38 - OE BOLT OE 255/45 R19 R line
Volkswagen Tiguan 3 2024 CT e1*2018/858*00302*.. WI238519 38_5_112M 5x112 57.1 38 - OE BOLT OE 255/45 R19 R line
Volvo C40 / EC40 2022 X e9*2007/46*3146*.. WI238519 56_5_108F 5x108 63.4 56 - OE BOLT OE 255/45 R19 only rear
e4*2007/46*3146*..;
Volvo XC40 P8 / EX40 2023 X WI238519 56_5_108F 5x108 63.4 56 - OE BOLT OE 255/45 R19 only rear
e9*2007/46*3146*..
CONDIZIONI e NOTE GENERALI / GENERIC CONDITION and NOTE
NOTA PRELIMINARE Solo se indicato come equipaggiamento originale (previsto dal costruttore) sulla carta di circolazione del veicolo.
PRELIMINARY NOTE Only if mentioned as original equipment (allowed by vehicle manufacturer) on the vehicle documents.
CATENABILITA' In merito alla catenabilità delle configurazioni indicate fare riferimento alle prescrizioni del costruttore del veicolo.
CHAINABILITY For the chainability of the listed configurations, please refer to the vehicle manufacturer’s prescriptions.
In caso di bulloneria originale del costruttore del veicolo utilizzare la coppia di serraggio prevista dallo stesso costruttore del veicolo.
BULLONERIA - COPPIA DI SERRAGGIO In caso di bulloneria aftermarket fornita da FONDMETAL S.p.A. fare riferiemnto alla prescrizioni di montaggio indicate nell'apposito opuscolo informativo all'interno della
scatola ruota.
In the case of original bolts/nuts, please follow the vehicle manufacturer’s tightening torque recommendations.
BOLT TIGHTENING TORQUE
In the case of aftermarket bolts/nuts supplied by FONDMETAL S.p.A., please make reference to the prescriptions in the leaflet supplied with the wheel.
Fare riferimento alle prescrizioni del costruttore del veicolo normalmente riportate tramite etichette sulle portiere, o all’interno del tappo della benzina o riportate sul manuale
PRESSIONE PNEUMATICI CONSIGLIATA
uso e istruzioni
Please make reference to the vehicle manufacturer’s recommendations, which are normally specified through labels on the vehicle doors or inside the petrol tank plug, or
RECOMMENDED TYRE PRESSURE
mentioned in the vehicle instructions manual.
COMPATIBILITA' TPMS Fare riferimento alla specifica FONDMETAL - TPMS Compatibility
TPMS COMPATIBILITY Please make reference to the speficic FONDMETAL - TPMS Compatibility
Pag. 2 di 2
